| Place of Origin: | SHENZHEN,CHINA |
|---|---|
| Brand Name: | RAYMO |
| Certification: | REACH/ CE/ ISO9000:2015/ ROHS/ SGS |
| Model Number: | WSO 102 A051 140+ |
| Minimum Order Quantity: | 5Piece/Pieces |
| Price: | Negotiable |
| Packaging Details: | Plastic Bag & Carton |
| Delivery Time: | 5-7wds |
| Payment Terms: | Western Union, L/C, D/A, D/P, T/T |
| Supply Ability: | 10000Pieces/ Month |
| Series: | Waterproof Circular Connectors | Shell Model: | Fischer WSO Elbow Connectors |
|---|---|---|---|
| Shell Size: | 0F/102,1F/103,AF/1031,2F/104 | Contact No.: | 2,3,4,5,7,9pins(2-19pins For Other Shell) |
| Connects Type: | PPS/PEEK Insulator With Solder Contacts | Application: | Test And Measurement |
| Highlight: | mil spec wire connectors,military cable connectors |
||
WSO Fischer elbow cable connector, waterproof IP68,WSO 102 A051 140 2pins 102 103 1031 104
Parts No.:RM-WSO-0F1S-P02JS50= WSO 102 A051 140+
| Description | |
| 1 | 100% substitute with original Fischer WSO elbow cable plug |
| 2 | right angle 2pins,male solder contacts with black shellIP68 circular cable connector |
| 3 | shell size 102,103,1031 and 104 |
| 4 | Sealed to IP68 and Hermetic |
| 5 | 360° EMC shield |
| 6 | Available Solder,PCB or right angle PCB contacts |
| 7 | Robust and shock resistant designs |
RAYMO is a manufacturer that:
♣ Manufacturing & exporting various metal & plastic circular connectors and cable assembly
♣ All prcts can be 100% compatible with original LEMO • FISCHER • • HIROSE • BINDERS and Military 38999
♣ Cable Assembly can be designed according customer real needs
♣ All the prcts we got CE, ROHS, SGS,ISO9000 certificate
♣ OEM connector and Cable assembly
• All the items can work normally after 5000 times mating
We can make all types of cables and connectors as per customers' request. Use any kind of connectors, like Hirose, Cannon, BNC, TNC, D-sub, USB, RJ45, Dtap, JST, Molex, and so on. Just tell us your need, leave the rest to RAYMO
| Technical Characteristics | |||
| Temperature Range | - 65° C, +200° C | Resistance to vibrations | 15 g [10 Hz - 2000 Hz] |
| Shock Resistance | 100 g [ 6 ms] | Salt spray corrosion test | >144hr |
| Climatical Category | 50/175/21 | Shielding (min) | > 75 dB [ at 10 MHz] > 40 dB [ at 1 GHz] |
| IP Rating | IP 68 | Certifications | ISO9001 CE ROHS2.0 SGS |
Why choose us:
If you couldn't find exact items you want,PLS kindly email us exact models you need, best price & each model specification details will be provided to you soon. Solve the original brand's high cost and long lead time!
