| Place of Origin: | SHENZHEN,CHIAN |
|---|---|
| Brand Name: | RAYMO |
| Certification: | SGS, RoHS, Reach, ISO:9001-2015, CE |
| Model Number: | DBPE 102 A053 130 |
| Minimum Order Quantity: | 1 Piece/Pieces |
| Price: | Negotiable |
| Packaging Details: | PE Bag & Carton |
| Delivery Time: | 3-5 working days |
| Payment Terms: | Western Union, T/T , MoneyGram, D/P, D/A, MoneyGram, L/C |
| Supply Ability: | 5000Pieces/ Week |
| Series: | IP68 Waterproof Connector | Shell Size: | 102/0F, 103/1F, 1031/AF, 104/2F |
|---|---|---|---|
| Contacts No.: | 2-19PINS | Insert Material: | PPS, PEEK |
| Shell Color: | Black Or Natural Chrome Plated Brass | Application: | Army, Navy, Air Force, Gendarmerie, Ministry Of National Defense And Coast Guard |
| Highlight: | mil spec wire connectors,military cable connectors |
||
SHENZHEN RAYMO ELECTRONICS TECHNOLOGY LIMITED has been specializing in prcing Waterproof Connector Metal Fast Lock for many years, we providing high quality waterproof metal connector Prcts. Quality is our priority. Raymo always attach great importance to quality controlling from the very beginning to the very end. Our factory has gained ISO9001. If you are searching for waterproof connector metal fast lock, please feel free to contact us.
| Temperature Range | - 65° C, +200° C | Resistance to vibrations | 15 g [10 Hz - 2000 Hz] |
| Shell Material | Brass with chrome plated | Humidity | up to 95% at 60° C/140F |
| Shock Resistance | 100 g [ 6 ms] | Salt spray corrosion test | >144hr |
| Climatical Category | 55/175/21 | Shielding (min) | > 95dB [ at 10 MHz], > 80 dB [ at 1 GHz] |
| IP Rating | IP 68 | Endurance(shell) | ≥5000 mating cycles |
If you have ordered this shell connector and know the original model P/N,please tell us.We will directly offer you our correspinding one.
If you don't know much about the connector,please make choose according the following factors:
The use of enviroment,indoor or ourdoors,waterproof or not
The panel hole size, to seclect the approproate plug and socket of right dimension
the current voltage and the realization of the function, to determin the cores
seclect the appropriate clam diameter and sheath
according to the actual needs of different angles of the keys, to determin the keying
100% compatible with lemo, , fischer connector
Help you save at least 50% cost
All the prcts we got CE, ROHS, SGS,ISO9000 certificate
Fast delivery: 2-15 working days
Cable assembly offer, help you save prction time
our company has over 9 years experience and strong professional research and development capabilities.Advanced development and management, comprehensice R&D TESTING and highly automatic prction line make our prcts high reliablilyty and high performance.
Our comapny has passed ISO90001,and got CE, REACH, RoHS and SGS certification
Solve the original brand's high cost and long lead time!
