| Place of Origin: | Guangdong, China |
|---|---|
| Brand Name: | RAYMO |
| Certification: | CE ROHS2.0 REACH ISO:9001-2015 |
| Model Number: | S SS WSO 1031 A010-130 |
| Minimum Order Quantity: | 10 Piece/Pieces |
| Price: | Negotiable |
| Packaging Details: | 150 pcs per 18*15*10 carton |
| Supply Ability: | 5000 Piece/Pieces per Week |
| Type: | SCART | Application: | Audio & Video |
|---|---|---|---|
| Gender: | Male | Connector Type: | 100% Compatible Connector |
| Shell Size: | 1031series | Molti-pole: | 10,12,19 Pins |
| Contacts (straight Or Elbow): | Solder, Print Or Crimp | Outer Shell Plated: | Chrome-plated Brass |
| Contact Plated: | Brass With Gold-plated | Insulator: | PPS |
| Protection Level: | IP68 | Certificate: | CE ROHS ISO9001 SGS |
| Port: | Shenzhen | ||
| Highlight: | waterproof wire connectors,waterproof electrical connectors |
||
| Connector Type Overview | Shell size | Contact no. | ||||||||||
| S/SS/SSC/WSO | 102/0F | 2 | 3 | 4 | 5 | 7 | 9 | |||||
| 103/1F | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 10 | 12 | 14 | 16 | |
| 1031/AF | 10 | 12 | 15 ( traxial ) | 19 | ||||||||
| 104/2F | 2 | 4 | 6 | 8 | 9 | 16 | 19 | |||||
| Pulling and inserting times | ＞5000 times |
| Humidity | Maximum humidity up to 95% at a temperature of 60 ° |
| Temperature range | - 65° C, +200° C |
| Vibration | 15 g [10 Hz - 2000 Hz] |
| Shock Resistance | 100 g [ 6 ms] |
| Salt Cpray Corrosion test | >96hr |
| Protention Level | IP 68 |
| Connector Type | Socket, female pins |
| Number of positions | 1-32pin |
| Contact Terminal | Solder |
| Fastensing Type | Push-pull |
| Shell Material | Brass |
| Shell Finish | Chrome Plated |
| Shell Colour | Silver, Black |
| Contact Material | Brass |
| Contact finish | Gold |
| Insert Material | PPS, PEEK |
RAYMO is a manufactuer that:
• Focus on manufacturing & exporting various metal & plastic circular push pull connectors, cable assembly.
• Can be 100% compatible with original LEMOS • FISCHERS • S • HIROSES • BINDERS •Military 38999
• Series has RM-B, RM-K, RM-S, RM-F,RM-E,RM-HR10A, RM-P, RM-M4, RM-M12, RM-M16, BNC, B680,
B423 , 38999, 26482
• CO, Form A, Form E for customer clearance
• CE, ROHS, ISO:90001-2008, SGA Audited manufacturer
• All the items can work normally after 5000times mating
Connector: 120pcs in 18*15*10cm carton box
Cable: 100pcs in 33*20*23cm carton box
1-300pcs:3-5 working days.
301-500pcs: 5-7 working days.
501-1000pcs: 7-10 working days.
OEM prct: 40-50 working days.
1. Are your company a professional manufacturer?
Raymo: Yes, we specialized in prcing circular push pull connectors and cable assembly since 2010.
We are SGS audited manufacuter, passed ISO9001-2008 Quality managerment system,
and worked on www.alibaba.com as a golden supplier more than 4 years. All the prcts meet CE ROHS standards.
2. What is the MOQ?
Raymo: No MOQ limited, depond on customer real needs.
3. Free sample :
RAYMO: Avaible. Any needs, pls contact us.
4. What about the delivery time?
Raymo: sample for 3-5 working days, mass prction for 5-7 working days.
5.What is your payment terms?
Raymo: 100% T/T deposite when customer place order.
6. Does your prct have any warranty?
Raymo: Yes, all of our connectors can work normally after 5000 cycles mating, our factory has instruments to tested them before shipping. Damage due to misuse, treatment and unauthorized modifications and repairs are not covered by our warranty.
