| Place of Origin: | Guangdong, China |
|---|---|
| Brand Name: | RAYMO |
| Model Number: | RM-S-AF, RM-SS-AF |
| Minimum Order Quantity: | 10 Piece/Pieces |
| Price: | Negotiable |
| Packaging Details: | 150 pcs per 18*15*10 carton |
| Supply Ability: | 5000 Piece/Pieces per Week |
| Application: | PCB | Shape: | Round |
|---|---|---|---|
| Shell Size: | 1031series | Molti-pole: | 10,12,19 Pins |
| Contacttype: | Solder, Print | Outer Shell Plated: | Chrome-plated Brass |
| Contact Plated: | Brass With Gold-plated | Insulator: | PPS |
| Protection Level: | IP68 | Certificate: | CE,ROHS,ISO9001,SGS |
| Color: | Silver, Black | Type: | SCART |
| Gender: | Male | Port: | Shenzhen |
| Highlight: | waterproof wire connectors,waterproof cable connector |
||
| Pulling and inserting times : ＞5000 times |
| Humidity : Maximum humidity up to 95% at a temperature of 60 ° |
| Temperature range: - 65° C, +200° C |
| Vibration: 15 g [10 Hz - 2000 Hz] |
| Shock Resistance : 100 g [ 6 ms] |
| Protention Level : IP50 |
| Salt Cpray Corrosion test: ＞96Hrs |
| Terminal Type: elbow PCB |
| Number of positions: 1-32pins |
| Fastensing Type: Push pull |
| Shell Material : Brass |
| Shell Finish : chrome plated |
| Contact Material: Brass |
| Insert Material : PPS , PEEK |
| F series | 0F/102 series | 2 | 3 | 4 | 5 | 6 | 7 | 9 | ||
| 1F/103 series | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 10 | 12 | |
| AF/1031 series | 10 | 12 | 19 | |||||||
| 2F/104 series | 19 |
RAYMO is a manufactuer that:
• Focus on manufacturing & exporting various metal & plastic circular push pull connectors, cable assembly.
• Can be 100% compatible with original LEMOS • FISHERS • S • HIROSES • BINDERS •Military 38999
• Series has RM-B, RM-K, RM-S, RM-F,RM-E,RM-HR10A, RM-P, RM-M4, RM-M12, RM-M16, BNC, B680,
B423 , 38999, 26482
• CO, Form A, Form E for customer clearance
• CE, ROHS, ISO:90001-2008, SGS Audited manufacturer
• All the items can work normally after 5000times mating
| Easy mating, can be blind-mated guiding mechanism ensures precise alignment |
| Increased safety and user friendliness mechanical and color coding prevent misconnection |
| Increased equipment life span guiding mechanism optimally protects the contacts |
| Robust and shock resistant designs ideal for equipment used in the field |
| High performance connectors designed and tested to withstand extreme conditions |
| Sealed up to IP50 and corrosion resistant usable underwater |
| Sterilizable ideal for medical applications |
| Functional in a wide temperature range from -65°C to +200°C |
