Home ProductsHalf Moon ConnectorFFA Plug Half Moon Connector , Circular Push Pull Connectors 00 0S 1S 2S Series

FFA Plug Half Moon Connector , Circular Push Pull Connectors 00 0S 1S 2S Series

FFA Plug Half Moon Connector , Circular Push Pull Connectors 00 0S 1S 2S Series
FFA Plug Half Moon Connector , Circular Push Pull Connectors 00 0S 1S 2S Series FFA Plug Half Moon Connector , Circular Push Pull Connectors 00 0S 1S 2S Series FFA Plug Half Moon Connector , Circular Push Pull Connectors 00 0S 1S 2S Series FFA Plug Half Moon Connector , Circular Push Pull Connectors 00 0S 1S 2S Series
Basic Information
Place of Origin: SHENZHEN,CHINA
Brand Name: RAYMO
Certification: CE/ROHS/SGS/ISO:9001-2015
Model Number: FFA.1S.304.CLAD52Z
Minimum Order Quantity: 1 Piece/Pieces
Price: Negotiable
Packaging Details: Plastic Bag & Carton
Delivery Time: 5-7working days
Payment Terms: T/T, Western Union, D/A, D/P,L/C, MoneyGram
Supply Ability: 5000Pieces/ Week
Contact Now
Prct Name: Half-moon Push Pull Connector Model: FFA Straight Plug
Shell Size: 00,0S,1S,2S Contact No.: 2-10 Pins, Coaxial
Insulator: PPS, PEEK Gender: Male, Female
Shell Color: Natural Or Black Shell IP Ranking: IP50
Contact Type: Solder/PCB/90° PCB Contacts Cable Assembled Or Not: Yes
Highlight:

pcb contacts connector

,

cable to cable connector

Prct Description

RM-S Series  00S 1S 2S 3S series Half-moon type circular push pull connectors with chrome plated FFA plug

Part No.:

FFA.1S.304.CLAD52Z / RM-FFA-1SC-304JS52Z

Prct Description:

1S size half-moon cable mount push pull connector, FFA plug, 4pin male contact, 52 cable collet, nut for a bend relief, natural chrome plated shell in brass



Main Feature



Half-moon type Push pull locking metal connector S-series connector, cable to cable connector, free socket, inline connector

1 Half-moon type Secure high performance push-pull Self-locking system
2 can be 100% compatible with original Lemo connector
3 Half-moon locking, coaxial locking
4 can plated with white or black chrome
5 Available solder and PCB or right angle PCB contact.
6 360° EMC shield
7 Certificate:ISO:9001-2015, CE ,RoHS2.0, SGS, Reach





Technical Chracteristics



Temperature Range - 65° C, +200° C Resistance to vibrations 15 g [10 Hz - 2000 Hz]
Shell Material Brass with chrome plated Humidity up to 95% at 60° C/140F
Shock Resistance 100 g [ 6 ms] Salt spray corrosion test >96hr
Climatical Category 50/175/21 Shielding (min) > 75 dB [ at 10 MHz],    > 40 dB [ at 1 GHz]
IP Rating IP 50 Endurance(shell) ≥5000 mating cycles



Prct Photo

FFA Plug Half Moon Connector , Circular Push Pull Connectors 00 0S 1S 2S Series 0



Contacts



Shell size Contacts no. ( Both with Solder & PCB type )
00 250        　 　 　 　 　 　 　 　 　
0S 250 2 3 4       　 　 　 　 　
1S 250 275 2 3 4 5 6
2S 250 275 2 3 4 5 6 7 8 10
3S 2 3 4 5 6 7 8 10 12 13 14 16 18



Our Company



RAYMO's high quality connectors are found in a variety of challenging applications and environments including:
Automotive, Audio-video, Aviation, Communications, Industrial Control, Information Systems, and Machines, Medical, Military, Test and Measurement, Data Acquisition, Data Transfer Equipment. Mle Power, Sensor,Sensor Systems Instrumentation, Analysis Application
FFA Plug Half Moon Connector , Circular Push Pull Connectors 00 0S 1S 2S Series 1
Our Exhibition
2020.11 Electronica Munich, Germany
2019 9.24-9.26 Testing Expo, Shanghai
2018 11.12-11.15 Electronica Munich, Germany
2017 9.11-9.16 NAB Show,Netherlands
2016 4.11-4.15 HK Fair
2015 10.2-10.7 ICEEB, Brasil
2014 10.11-10.15 HK Fair
2014 4.11-4.15 HK Fair
Why Choose US?

FFA Plug Half Moon Connector , Circular Push Pull Connectors 00 0S 1S 2S Series 2

If you couldn't find exact items you want,PLS kindly email us exact models you need, best price & each model specification details will be provided to you soon. Solve the original brand's high cost and long lead time!
