| Place of Origin: | Shenzhen, Guangdong, China |
|---|---|
| Brand Name: | RAYMO |
| Certification: | SGS, RoHS, Reach, ISO:9001-2015 |
| Model Number: | FVG.1W.306.CLAC52Z |
| Minimum Order Quantity: | 1 Piece/Pieces |
| Price: | Negotiable |
| Packaging Details: | PE Bag & Carton |
| Delivery Time: | 3-5 working days |
| Payment Terms: | Western Union, T/T , MoneyGram, D/P, D/A, MoneyGram, L/C |
| Supply Ability: | 5000Pieces/ Week |
| Type: | Circular Waterproof Connector | Contact No.: | 2-16pins |
|---|---|---|---|
| Compayible: | LEMO FVG Plug | Insert Material: | PPS, PEEK |
| IP Ranking: | IP68 | Shell Colour: | Natural Or Black Chrome Plated Brass |
| Highlight: | outdoor electrical connector,waterproof dc connector |
||
|
PARTS No. |
Raymo P/N |
LEMO Redel P/N |
|
RM-FVG-1WC-306-JS52Z |
FVG.1W.306.CLAC52Z |
straight plug with key (G), 1W series, multipole type with 6 contacts, outer shell in chromeplated brass, PPS insulator, male solder contacts, C type collet for 5.2 mm diameter cable.
FVG 1W 6pins can mate with LEMO FVG connector but more cheaper and short lead time
SHENZHEN RAYMO ELECTRONICS TECHNOLOGY LIMITED has been specializing in prcing Waterproof Connector Metal Fast Lock for many years, we providing high quality waterproof metal connector Prcts. Quality is our priority. Raymo always attach great importance to quality controlling from the very beginning to the very end. Our factory has gained ISO9001, If you are searching for waterproof connector metal fast lock, please feel free to contact us.
Connectors can corss with LEMO, Fischer, , BINDER, HIROSE and 38999.
Multipole types from 2 to 16 contacts
Solder or crimp contacts
Keying system («G» key standard) for connector alignment
Multiple key options to avoid cross mating of similar connectors
360° screening for full EMC shielding
Rugged housing for extreme working conditions.
The basic elements, insulators, contacts and clamping system are from the B series. The push-pull latching system has been replaced by a screw coupling system with watertightness
Test and measurement
Industrial electronics
Automotive
Aviation
Industrial Control
Information Systems
Military
Data Transfer Equipment
Sensor & Sensor Systems Instrumentation
| Temperature Range | - 65° C, +200° C | Resistance to vibrations | 15 g [10 Hz - 2000 Hz] |
| Shell Material | Brass with chrome plated | Humidity | up to 95% at 60° C/140F |
| Shock Resistance | 100 g [ 6 ms] | Salt spray corrosion test | >144hr |
| Climatical Category | 55/175/21 | Shielding (min) | > 95dB [ at 10 MHz], > 80 dB [ at 1 GHz] |
| IP Rating | IP 68 | Endurance(shell) | ≥5000 mating cycles |
100% compatible with lemo, , fischer connector
Help you save at least 50% cost
All the prcts we got CE, ROHS, SGS,ISO9000 certificate
Fast delivery: 2-15 working days
Cable assembly offer, help you save prction time
our company has over 9 years experience and strong professional research and development capabilities.Advanced development and management, comprehensice R&D TESTING and highly automatic prction line make our prcts high reliablilyty and high performance.
Our comapny has passed ISO90001,and got CE, REACH, RoHS and SGS certification
|
2020.11 |
Electronica Munich, Germany |
|
2019 9.24-9.26 |
Testing Expo, Shanghai |
|
2018 11.12-11.15 |
Electronica Munich, Germany |
|
2017 9.11-9.16 |
NAB Show,Netherlands |
|
2016 4.11-4.15 |
HK Fair |
|
2015 10.2-10.7 |
ICEEB, Brasil |
|
2014 10.11-10.15 |
HK Fair |
|
2014 4.11-4.15 |
HK Fair |
If you couldn't find exact items you want,PLS kindly email us exact models you need, best price & each model specification details will be provided to you soon. Solve the original brand's high cost and long lead time!
