| Place of Origin: | CHINA |
|---|---|
| Brand Name: | RAYMO |
| Certification: | RoHs2.0 CE ISO9001 |
| Model Number: | 678 series 99 0603 00 02 |
| Minimum Order Quantity: | 1 Piece/Pieces |
| Price: | Negotiable |
| Packaging Details: | Plastic Bag & Carton |
| Delivery Time: | 5-7working days |
| Payment Terms: | T/T, D/A, D/P,L/C, MoneyGram, Western Union |
| Supply Ability: | 5000Pieces/ Week |
| Prct Name: | Bayonet Locking System | Shell Size: | 678 Series DIN Connector |
|---|---|---|---|
| Contact No.: | 3, 4, 5, 6,7 ,8, 12 | Insulator: | PBT |
| Shell Material: | PA66 | ||
| Highlight: | threaded wire connectors,metal circular connector |
||
| Shell body | PA66 |
| Insulating body | PBT |
| Contact pin | CuZn, silver-plated and flash goldplated |
| Sleeve | PC |
| Bend protection sleeve | TPE |
| Screw steel | Nickel-plated |
| Wire gauge | max, 0.75mm²(max. AWG 20) ( 3-8 poles) |
| max, 025mm²(max. AWG 24) (12 poles ) | |
| Cable outlet | 3-6mm/6-8mm |
| Mechanical opera | >500 ma |
| Upper temperature | + 85 °C |
| Lower temperature | – 40 °C |
| Rated voltage | 250 V (32 V) 2-4 poles |
| 60 V (32 V) 5 poles | |
| 250 V (32 V) 6poles | |
| 125V (32 V) 7poles | |
| 60 V (32 V), 8-12poles | |
| Rated impulse voltage | 1500V 2-6poles |
| 800V 7 poles | |
| 500V (32 V)8-12poles | |
| Rated current (40 °C) | 7A 2-3 poles |
| 6A 4-6 poles | |
| 5A 7-8poles | |
| 3A 12poles | |
| Contact resistance | ≤ 5 MΩ 3-8 poles |
| ≤ 3 mΩ 12poles |
| Q1. Raymo is factory or not? |
| 100% Manufacturer. |
| Q1. What is your terms of packing? |
| A: Generally, we pack our goods in PE bag and brown cartons. If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters. |
| Q2. What is your terms of payment? |
| A: T/T 100% or Paypal are both OK. But If your order is big, you can T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the prcts and packages before you pay the balance. |
| Q3. What is your terms of delivery? |
| A: FOB SHENZHEN |
| Q4. How about your delivery time? |
| A: Generally, it will take 5~7 working days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order. |
| Q5. Can you prce according to the samples? |
| A: Yes, we can prce by your samples or technical drawings. We can build the molds and fixtures. |
| Q6. What is your sample policy? |
| A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost. |
| Q7. Do you test all your goods before delivery? |
| A: Yes, we have 100% test before delivery. |
| Q8: How do you make our business long-term and good relationship? |
| A:1. We keep good quality and competitive price to ensure our customers benefit ; 2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from. |
If you couldn't find exact items you want,PLS kindly email us exact models you need, best price & each model specification details will be provided to you soon. Solve the original brand's high cost and long lead time!
