| Place of Origin: | SHENZHEN,CHINA |
|---|---|
| Brand Name: | RAYMO |
| Certification: | RoHs2.0 CE ISO9001 |
| Model Number: | 09 0303 89 02 |
| Minimum Order Quantity: | 1 Piece/Pieces |
| Price: | Negotiable |
| Packaging Details: | Plastic Bag & Carton |
| Delivery Time: | 5-7working days |
| Payment Terms: | T/T, D/A, D/P,L/C, MoneyGram, Western Union |
| Supply Ability: | 5000Pieces/ Week |
| Prct Name: | Threaded Electrical Connector | Shell Size: | 680 Series DIN Connector |
|---|---|---|---|
| Contact No.: | 3, 4, 5, 6,7 ,8, 12 | Insulator: | PBT |
| Shell Material: | Brass | ||
| Highlight: | threaded wire connectors,metal circular connector |
||
Binder M16 680 Series Threaded Electrical Connector,Male panel mount connector IP40 09 0303 89 02
M16 series connector equivalent as Binder Series 680 678 423, 723 family of connectors are rugged, high-performance circular connectors with excellent EMI shielding . Ideal choice for severe industrial and commercial applications. Panel-mounted receptacle are available in many styles and mounting methods.
| Wire gauge | max, 0.75mm²(max. AWG 20) ( 3-8 poles) |
| max, 025mm²(max. AWG 24) (12 poles ) | |
| Cable outlet | 3-6mm/6-8mm |
| Mechanical opera | >500 ma |
| Upper temperature | + 85 °C |
| Lower temperature | – 40 °C |
| Rated voltage | 250 V (32 V) 2-4 poles |
| 60 V (32 V) 5 poles | |
| 250 V (32 V) 6poles | |
| 125V (32 V) 7poles | |
| 60 V (32 V), 8-12poles | |
| Rated impulse voltage | 1500V 2-6poles |
| 800V 7 poles | |
| 500V (32 V)8-12poles | |
| Rated current (40 °C) | 7A 2-3 poles |
| 6A 4-6 poles | |
| 5A 7-8poles | |
| 3A 12poles | |
| Contact resistance | ≤ 5 MΩ 3-8 poles |
| ≤ 3 mΩ 12poles |
If you couldn't find exact items you want,PLS kindly email us exact models you need, best price & each model specification details will be provided to you soon. Solve the original brand's high cost and long lead time!
