| Place of Origin: | CHINA |
|---|---|
| Brand Name: | RAYMO |
| Certification: | ISO:9001-2015 |
| Model Number: | ECG.0B.302.CLN |
| Minimum Order Quantity: | 1 Piece/Pieces |
| Price: | Negotiable |
| Packaging Details: | Plastic Bag & Carton |
| Delivery Time: | 5-7working days |
| Payment Terms: | T/T, PAYPAL, EBAY |
| Supply Ability: | 5000Pieces/ Week |
| Shell Size: | 0B Series | Contact No.: | 2pin Female Contact |
|---|---|---|---|
| Prct Name: | PCB Connector | Insulator: | PPS |
| Shell Material: | Cuzn | Terminal: | PCB |
| Highlight: | pcb board connector,right angle pcb connector |
||
| Connector Descitption Details: | |||
| Shell model | ECG type | Shell size | 00B 0B 1B 2B 3B 4B 5B |
| Gender | Male | Contact No. | 2,3,4,5,6,7,8,9,10,12,14,16,19,30,32, |
| MOQ | 1pc | Delivery | 2-5 working days |
| Endurance(shell) | 5000 mating cycles | Humidity | up to 95% at 60° C/140F |
| Technical Characteristics | |||
| Temperature Range | - 65° C, +250° C | Resistance to vibrations | 15 g [10 Hz - 2000 Hz] |
| Shell Material | Brass with chrome plated | Humidity | up to 95% at 60° C/140F |
| Shock Resistance | 100 g [ 6 ms] | Salt spray corrosion test | >144hr |
| Climatical Category | 50/175/21 | Shielding (min) | > 75 dB [ at 10 MHz], > 40 dB [ at 1 GHz] |
| IP Rating | IP 50 | Endurance(shell) | 5000 mating cycles |
If you couldn't find exact items you want,PLS kindly email us exact models you need, best price & each model specification details will be provided to you soon. Solve the original brand's high cost and long lead time!
