| Place of Origin: | CHINA |
|---|---|
| Brand Name: | RAYMO |
| Certification: | ISO:9001-2015, SGS, REACH 2.0, CE, RoHS |
| Model Number: | EPG.0B.309.HLN |
| Minimum Order Quantity: | 1 Piece/Pieces |
| Price: | Negotiable |
| Packaging Details: | Plastic Bag & Carton |
| Delivery Time: | 5-7working days |
| Payment Terms: | T/T, PAYPAL, EBAY |
| Supply Ability: | 5000Pieces/ Week |
| Type: | Panel PCB Connector | Shell Size: | 0B, 1B |
|---|---|---|---|
| Contact No.: | 9 Pins Female Contact | Terminal: | PCB Contacts |
| Insulator: | PPS | ||
| Highlight: | circuit board connectors,right angle pcb connector |
||
| Shell model | Elbow EPG | Shell size | 0B 1B |
| Gender | Female | Contact No. | 2,3,4,5,6,7,8,9,10,12,14 , |
| MOQ | 1pc | Delivery | 5-7 working days |
| Endurance(shell) | 5000 mating cycles | Humidity | up to 95% at 60° C/140F |
| Temperature Range | - 65° C, +200° C | Resistance to vibrations | 15 g [10 Hz - 2000 Hz] |
| Shell Material | Brass with chrome plated | Humidity | up to 95% at 60° C/140F |
| Shock Resistance | 100 g [ 6 ms] | Salt spray corrosion test | >96hr |
| Climatical Category | 50/175/21 | Shielding (min) | > 75 dB [ at 10 MHz], > 40 dB [ at 1 GHz] |
| IP Rating | IP 50 | Endurance(shell) | 5000 mating cycles |
SHENZHEN RAYMO ELECTRONICS TECHNOLOGY LIMITED is a manufacturer located in Shenzhen, focusing on manufacturing Creative customer-oriented metal and plastic circular push-pull self-latching connectors and cable assemblies to serve over 75 countries and regions since 2010. Our prcts got very popular recommendation among our customers.
This vast portfolio enables you to select the ideal connector configuration to suit almost any specific requirement in most markets inclyding medical devices, test and measurement instruments, machinery, audio video broadcast, telecommunications and military
If you couldn't find exact items you want,PLS kindly email us exact models you need, best price & each model specification details will be provided to you soon. Solve the original brand's high cost and long lead time!
1.Can I order a small list ?
Raymo:Of course, you can.
2.What quote do you offer?
Raymo:FOB , CIF and others ways according the your needs.
3.How transport?
Raymo:Sea Freight, Air Freight and others Express Delivery ways for you.
4.What is the quality of your prcts guarantee?
We have passed ISO9001:2015 Quality Management System Certification, CQM Quality Management System Certification and IQNet Quality Management System Certification, If the quality doesn't accord the standard, you can exchange the goods for free.
5.Do you have after-sales service?
Raymo:Certainly,you can contact us at any time.
