| Place of Origin: | Guangdong, China |
|---|---|
| Brand Name: | RAYMO |
| Certification: | CE / RoHS / SGS / ISO9001:2015 |
| Model Number: | RM-PLG-1PC-305KS |
| Minimum Order Quantity: | 1 pcs |
| Price: | Negotiable |
| Packaging Details: | PE bag & carton |
| Delivery Time: | 5-8 working days |
| Payment Terms: | T/T |
| Supply Ability: | 5000pcs per week |
| Connector Style: | PLG All In One Type Fixed Socket | Series: | 1P |
|---|---|---|---|
| Contact No.: | 5 Pin (2, 3, 4 ...... 14 Pins Are Available) | Contact Type: | Female Solder Contacts |
| Insulator: | PPS Or PEEK | Housing: | Grey PC (Blue, Green, Yellow, Red, Black, |
| Front Nut Color: | Gree (Yellow, Blue, Black, Red, Grey Color Are Aviailable) | Contact Material: | Brass With Gold Plated |
| Contact Dia.: | 0.9 Mm | Rated Current: | 9 A |
| IP Rating: | IP50 | Cable Assemblies: | Yes |
| Highlight: | plastic push pull connector,cable assembly connector |
||
Prct Description
P/N: RM-PLG-1PC-305KS
Description: PLG fixed socket, all in one type, 1P series, 1 key (G), 0 degree, 5 pin female contacts in solder type, PPS insulator, outer shell in grey PC.
|
Shell size |
Contacts No. with solder & PCB type |
|
1P |
2, 3, 4, 5, 6, 7, 8, 9, 10, 12, 14 |
Specifications
Technical Characteristics
|
Endurance |
>1000 cycles |
Salt spray corrosion test |
>72h |
|
Humidity |
Up to 95% at 60℃ |
Protection Index (mated) |
IP50 |
|
Temperature Range |
-40°C ~ +150°C |
Climatical category |
55/175/21 |
|
Resistance to Vibration |
10-2000Hz,15g |
Shielding |
>75db at 10MHZ >40db at 1GHZ |
|
Shock Resistance |
100g, 6ms |
Certification |
CE, RoHS, SGS |
Photo & Dimensions:
Application
RAYMO's high quality connectors are found in a variety of challenging applications and environmetns including:
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Packing & Delivery
Packing:
PE bag & Carton
Delivery Time:
1~10pcs: 3~5 working days
11~100pcs: 3~5 working days
101~500pcs: 3~5 working days
501~1000pcs: 3~5 working days
