| Place of Origin: | China |
|---|---|
| Brand Name: | RAYMO |
| Certification: | ISO9001/ CE/ ROHS2.0/ SGS |
| Model Number: | RM-PAG-1PC-304-JS42J |
| Minimum Order Quantity: | 1pcs |
| Price: | negotiation |
| Packaging Details: | carton |
| Delivery Time: | 5-7 working days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 5000pcs per week |
| Prct Name: | Circular Plastic Connectors | Application: | Medical Electronics |
|---|---|---|---|
| Shell Size: | 1P | Contacts: | 2,3,4,5,6,7,8,9,10,14P |
| Contact Material: | Copper | Protection Index: | IP50 |
| OEM: | Acceptable | Sample: | Freely |
| Highlight: | 1P Shell Circular Plastic Connectors,IP50 Circular Plastic Connectors,PPS Insulator Plastic Electrical Connectors |
||
Medical Electronics Alternative Cable Plug Circular Plastic Connectors
Prct Description:
RM-P series are mainly used in medical world. compatible with original, and these can be sterilizable. Single-use (called disposable connectors too) are also available when sterilization is not an option.
These circular plastic connectors are especially adapted for applications such as medical electronics and test & measurement.
Example: RM-PAG-1PC-304-JS42J=PAG.M0.7GL.AC42J
Straight plug with cable collect and alignment key(G=0 degree), multipin 4 male contacts in solder type, gray PC outer shell, PPS insulator, collet for 3.2-4.2mm diameter cable nut for fitting a bend relief, with a yellow color bend relief.
| Shell size | Contacts no. With Solder & PCB type | |||||||||
| 1P | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 14 |
| Nut color | Gray(G) | blue(A) | yellow(J) | black(N) | red(R) | green(V) |
Features of RM-P series medical push pull circular plastic connector:
-Lightweight
-Secure high performance push-pull self-locking system
-High pin density contributing to equipment miniaturization
-Contacts from 2-14pins
-Alignment Key and Polarized Keying System to avoid cross-interface
-Colorful nut for choice, easy for identify
-Functional in a wide temperature range from -50°C to +150°C
-Available solder, PCB and right angle PCB contact
Applications of Circular plastic Connectors
•Medical electronics
•Test and measurement
•Industrial electronics
•Automotive
Our company
With professional R&D and excellent craftsmanship, our factory has ability of providing customer with much more precision connectors and cable harness solutions to meet customer's demand in this fields.
Aimed on providing customer with qualified and suitable connectors and cable assemblies, our factory has already designed and developed over 3,000 types of connectors and 1,000 kinds of OEM cable assemblies based on customer real needs since the establishment.
FAQ
-What is your terms of payment?
A: T/T 100% or Alibaba on-line order are both OK.
-What is your sample policy?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.
-Does your company a professional manufacturer?
A: Yes, we specialized in prcing circular push pull self-latching connectors and cable assembly since 2010.Our factory is SGS audited manufacturer and worked on www.alibaba.com more than 7 years.
-Can I use my own logo on the prcts?
A:Yes, customers' logo, size and design are acceptable, OEM&ODM are welcomed.
-Does your prct have any warranty?
A: Yes, all of our connectors can work normally after 5000 cycles mating; our factory
has instruments to tested them before shipping.
