| Place of Origin: | China |
|---|---|
| Brand Name: | RAYMO |
| Certification: | ISO9001/ CE/ ROHS2.0/ SGS |
| Model Number: | RM-PKG |
| Minimum Order Quantity: | 1pcs |
| Price: | negotiation |
| Packaging Details: | carton |
| Delivery Time: | 5-7 working days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 5000pcs per week |
| Prct Name: | Circular Plastic Connectors | Application: | Data Signal Power Transfer |
|---|---|---|---|
| Shell Size: | 1P | Contacts: | 2,3,4,5,6,7,8,9,10,14P |
| Color: | Gray, Yellow, Black, Red, Green, Blue. | Termination: | Solder, PCB, Right Angle PCB |
| OEM: | Acceptable | Sample: | Freely |
| Highlight: | 1P Shell Circular Plastic Connectors,18.5mm Circular Plastic Connectors,PPS Panel Mount Circular Connectors |
||
Panel Mounted Female Receptacle Socket 18.5mm Circular Plastic Connectors
Prct Description:
RM-P series are mainly used in medical world. compatible with original, and these can be sterilizable. Single-use (called disposable connectors too) are also available when sterilization is not an option. The Push-Pull connectors are easy to manipulate and are available in IP50 and IP68 version.
These circular plastic connectors are especially adapted for applications such as medical electronics and test & measurement.
| Raymo P/N | Original P/N |
| RM-PKG-1PC-302-KSA | PKG.M0.2GL.LA |
| RM-PKG-1PC-303-KSA | PKG.M0.3GL.LA |
| RM-PKG-1PC-304-KSA | PKG.M0.4GL.LA |
| RM-PKG-1PC-305-KSA | PKG.M0.5GL.LA |
| RM-PKG-1PC-306-KSA | PKG.M0.6GL.LA |
| RM-PKG-1PC-307-KSA | PKG.M0.7GL.LA |
| RM-PKG-1PC-308-KSA | PKG.M0.8GL.LA |
| RM-PKG-1PC-309-KSA | PKG.M0.9GL.LA |
| RM-PKG-1PC-310-KSA | PKG.M0.10GL.LA |
| RM-PKG-1PC-314-KSA | PKG.M0.14GL.LA |
| Shell size | Contacts no. With Solder & PCB type | |||||||||
| 1P | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 14 |
| Nut color | Gray(G) | blue(A) | yellow(J) | black(N) | red(R) | green(V) |
Example:
RM-PKG-1PC-303-KSR=PKG.M0.3GL.LR
Fixed receptacle with two nuts and alignment key(G=0 degree), multipole 3 female contacts in solder type, gray color PC outer shell, PPS insulator, red color plastic front nut.
Features of RM-P series medical push pull circular plastic connector:
-Push-Pull self-latching
-Secure high performance push-pull self-locking system
-2 sizes
-Contacts from 2-14pins
-Temp. range -50°C to 150°C
-White, gray or black outer shell
-For cable ø 2.7 to 6.5 mm
-Available solder, PCB and right angle PCB contact
Applications of Circular plastic Connectors
•Medical electronics
•Test and measurement
•Industrial electronics
•Automotive
