| Place of Origin: | SHENZHEN,CHINA |
|---|---|
| Brand Name: | RAYMO |
| Certification: | RoHS2.0, ISO:9001-2015, CE , SGS, REACH |
| Model Number: | EGJ.1B.305.CLA |
| Minimum Order Quantity: | 5 Piece/Pieces |
| Price: | Negotiable |
| Packaging Details: | Plastic Bag & Carton |
| Delivery Time: | 5-7wds |
| Payment Terms: | Western Union, L/C, D/A, D/P, T/T |
| Supply Ability: | 5000Pieces/ Week |
| Type: | Aviation Circular Push Pull Connectors | Shell Size: | 1B (Other Shell Size Is Available) |
|---|---|---|---|
| Contact No.: | 2.3.4.5.6.7.8.9.10.14.16 Pins | Insulator: | PPS |
| Endurance: | 5000 Times Push Pull | Contact Material: | Copper Alloy Plated With Gold |
| Highlight: | 1B Shell Electronics Component Connectors,SGS Circular Power Connector,SGS Cable Mount Connector |
||
Double Slot 1B Shell Electronics Component Connectors 45 Degree
Aviation circular push pull connector, double slot FGJ EGJ 0B 1B 45 degree double key connector, EGJ.1B.305
|
Temperature Range |
- 40° C, +125° C |
Resistance to vibrations |
15 g [10 Hz - 2000 Hz] |
|
Shell Material |
Brass with chrome plated |
Humidity |
up to 95% at 60° C/140F |
|
Shock Resistance |
100 g [ 6 ms] |
Salt spray corrosion test |
>144hr |
|
Climatical Category |
50/175/21 |
Shielding (min) |
> 75 dB [ at 10 MHz], > 40 dB [ at 1 GHz] |
|
IP Rating |
IP50 |
Endurance(shell) |
5000 mating cycles |
|
1
|
push-pull self-locking connector, 100% compatible with original LEMO connector
|
|
2
|
a variety of size optional(00B, 0B, 1B, 2B, 3B)
|
|
3
|
solder or crimp core; straight or 90 degree
|
|
4
|
meet the most industries (like medical equipment, test equipment, machinery, audio and video broadcasting, telecommunications and military, etc.) any one of the special application requirements
|
|
5
|
360 degree complete EMC shielding, shock resistance, vibration resistance and corrosion resistance
|
|
6
|
you can buy FGG or EGG connector separately, or both
|
Contacts And Model
|
LEMO Type
|
Raymo Type
|
Pins
|
| EGJ.1B.305.CLA |
RM-EGJ-1BC-.305-JS
|
8
|
|
0B
|
RM-0B
|
2 3 4 5 6 7 9
|
|
1B
|
RM-1B
|
2 3 4 5 6 7 8 10 12 14 16
|
|
2B
|
RM-2B
|
2 3 4 5 6 7 8 10 12 16 19 20 26
|
|
3B
|
RM-3B
|
3 4 6 8 9 10 12 14 16 18 21 226 30 32
|
| 4B | RM-4B |
7 10 24 |
RAYMO is a manufactuer that:
1. Are your company a professional manufacturer?
Raymo: Yes, we specialized in prcing circular connectors and cable assembly since 2010.Our factory is SGS audited manufacturer and worked on www.alibaba.com more than 9 years.
2. What is the MOQ?
Raymo: No MOQ limited, small order is accepted, all is depend on customer real needs.
3. Free sample :
Raymo: Available. Any needs, please contact us.
4. What about the delivery time?
Raymo: sample for 3-5 working days, mass prction for 5-7 working days.
5. What is your payment terms?
Raymo: 100% T/T deposit when customer place order.
6. Does your prct have any warranty?
Raymo: Yes, all of our connectors can work normally after 5000 cycles mating; our factory
has instruments to tested them before shipping.
Damage due to misuse, treatment and unauthorized modifications and repairs are not covered by our warranty.
If you couldn't find exact items you want,PLS kindly email us exact models you need, best price & each model specification details will be provided to you soon. Solve the original brand's high cost and long lead time!
