Electrical IP50 Circular Push Pull Connectors 5000 Times PPS Insulator

Electrical IP50 Circular Push Pull Connectors 5000 Times PPS Insulator
Electrical IP50 Circular Push Pull Connectors 5000 Times PPS Insulator
Electrical IP50 Circular Push Pull Connectors 5000 Times PPS Insulator
Basic Information
Place of Origin: SHENZHEN,CHINA
Brand Name: RAYMO
Certification: CE REACH RoHS ISO9000-2015
Model Number: EGJ.1B.305.CLA
Minimum Order Quantity: 5 Piece/Pieces
Price: Negotiable
Packaging Details: Plastic Bag & Carton
Delivery Time: 5-7wds
Payment Terms: Western Union, L/C, D/A, D/P, T/T
Supply Ability: 5000Pieces/ Week
Contact Now
Type: Aviation Circular Push Pull Connectors IP Rating: IP50
Contact No.: 2.3.4.5.6.7.8.9.10.14.16 Pins Insulator: PPS
Endurance: 5000 Times Push Pull Contact Material: Copper Alloy Plated With Gold
Highlight:

IP50 Circular Push Pull Connectors

,

PPS Circular Push Pull Connectors

,

IP50 Circular Electrical Connectors

Electrical IP50 Circular Push Pull Connectors 5000 Times PPS Insulator



Aviation circular push pull connector, double slot FGJ EGJ 0B 1B 45 degree double key connector, EGJ.1B.305



Main Features
1



 push-pull self-locking connector, 100% compatible with original LEMO connector
2 a variety of size optional(00B, 0B, 1B, 2B, 3B)
3 solder or crimp core; straight or 90 degree



4
meet the most industries (like medical equipment, test equipment, machinery, audio and video broadcasting, telecommunications and military, etc.) any one of the special application requirements
5 360 degree complete EMC shielding, shock resistance, vibration resistance and corrosion resistance
6 you can buy FGG or EGG connector separately, or both



Application
  • Broadcast like Studios and outside broadcasting
  • Instrumentation like Test & measurement
  • Medical like Diagnostic devices
  • Transport Avionics
  • Energy like Nuclear
  • Defense & Security like Communication systems
  • Extreme like Motorsports

Parts Description
Technical Characteristics

Temperature Range

- 40° C, +125° C

Resistance to vibrations

15 g [10 Hz - 2000 Hz]

Shell Material

Brass with chrome plated

Humidity

up to 95% at 60° C/140F

Shock Resistance

100 g [ 6 ms]

Salt spray corrosion test

>144hr

Climatical Category

50/175/21

Shielding (min)

> 75 dB [ at 10 MHz], > 40 dB [ at 1 GHz]

IP Rating

IP50

Endurance(shell)

5000 mating cycles


Contacts And Model

LEMO Type
Raymo Type
Pins
EGJ.1B.305.CLA
RM-EGJ-1BC-.305-JS
8
0B
RM-0B
2 3 4 5 6 7 9
1B
RM-1B
2 3 4 5 6 7 8 10 12 14 16
2B
RM-2B
2 3 4 5 6 7 8 10 12 16 19 20 26
3B
RM-3B
3 4 6 8 9 10 12 14 16 18 21 226 30 32
4B RM-4B

7 10 24

Company Intrce

RAYMO is a manufactuer that:

  • Focus on manufacturing & exporting various metal & plastic circular push pull connectors, cable assembly.
  • Can be 100% compatible with original LEMO • •FISCHER• HIROSE • BINDER •Military 38999
  • Series has RM-B, RM-K, RM-S, RM-F,RM-E,RM-HR10A, RM-P, RM-M4, RM-M12, RM-M16, BNC, B680,B423 , 38999, 26482
  • CO, Form A, Form E for customer clearance
  • CE, ROHS, REACH, ISO:90001-2015, SGS Audited manufacturer
  • All the items can work normally after 5000times mating
Dimensions and Keying

Electrical IP50 Circular Push Pull Connectors 5000 Times PPS Insulator 0

Electrical IP50 Circular Push Pull Connectors 5000 Times PPS Insulator 1



Certificate
  • CE
  • REACH
  • RoHS
  • ISO9000-2015
Advantages
  • 8 years focus on connectors
  • professional teams in R&D,manufacture,quality testing and export sales to make sure your connectors perfect and have relatively low prices
  • customized your own connectors according to your requirement
  • Factory supplier,provide fast delivery and perfect after-sales service you can purchase without scruple.
  • Help customers to make model selection : Just e-mail us and give the prtion information
RFQ

1. Are your company a professional manufacturer?
Raymo: Yes, we specialized in prcing circular connectors and cable assembly since 2010.Our factory is SGS audited manufacturer and worked on www.alibaba.com more than 9 years.
2. What is the MOQ?
Raymo: No MOQ limited, small order is accepted, all is depend on customer real needs.
3. Free sample :
Raymo: Available. Any needs, please contact us.
4. What about the delivery time?
Raymo: sample for 3-5 working days, mass prction for 5-7 working days.
5. What is your payment terms?
Raymo: 100% T/T deposit when customer place order.
6. Does your prct have any warranty?
Raymo: Yes, all of our connectors can work normally after 5000 cycles mating; our factory
has instruments to tested them before shipping.
Damage due to misuse, treatment and unauthorized modifications and repairs are not covered by our warranty.

If you couldn't find exact items you want,PLS kindly email us exact models you need, best price & each model specification details will be provided to you soon. Solve the original brand's high cost and long lead time!
