| Place of Origin: | Shenzhen, Guangdong, China |
|---|---|
| Brand Name: | RAYMO |
| Certification: | RoHS, Reach, SGS, ISO:9001-2015 |
| Model Number: | D38999/20WD05PN |
| Minimum Order Quantity: | 1 Piece/Pieces |
| Price: | Negotiable |
| Packaging Details: | PE Bag & Carton |
| Delivery Time: | 15-20 days |
| Payment Terms: | Western Union, T/T , MoneyGram, D/P, D/A, MoneyGram, L/C |
| Supply Ability: | 5000Pieces/ Week |
| Connector Type: | Receptacle | Orientation: | Straight |
|---|---|---|---|
| Contact Type: | Male Pin | Number Of Positions: | 5 |
| Contact Arrangement: | 15-5 | Mounting Type: | Panel Mount |
| Highlight: | FGG.0B.305.CLAD42Z LEMO Push Pull Connector,5 Pin LEMO Push Pull Connector,FGG.0B.305.CLAD42Z |
||
GJB599A series are made according to the same standard with MIL-DTL-38999K series. The difference is that: the basic part number of GJB599A is MS, while MIL-DTL-38999K is MS. GJB599A series is interchangeable with MIL-DLT-38999K series.
| Category | Military Circular Connectors |
| Part number | D38999/20WD05PN |
| Connector Type | Receptacle |
| Orientation | Straight |
| Contact Type | Male Pin |
| Number of Positions | 5 |
| Fastening Type | Threaded |
| Mounting Type | Panel Mount |
| Contact Termination | Crimp |
| Protection Rating | IP67 |
| Housing | Aluminum alloy/stainless steel |
| Plating |
B class: olive green cadmium plating E class: stainless steel passive F class: electroness nickel plating |
| Insulator | Thermoset plastic |
| Grommet and seal | Silicon rubber |
| Contact |
Gold-plated copper alloy, crimping, soldering, PCB |
| Endurance | 500 cycles |
| Vibration |
Sinusoid vibration: frequency 10-2000Hz, acceleration: 294m/s2 Random vibration: frequency 100-1000Hz, power spectral density: 1g2/Hz |
| Shock | At 3 ms half sinusoid, peak value |
| Operating temperature |
B class: -65℃～+175℃ E, F class: -65℃～+200℃ |
This vast portfolio enables you to select the ideal connector configuration to suit almost any specific requirement in most markets inclyding medical devices, test and measurement instruments, machinery, audio video broadcast, telecommunications and military
As a professional in design and manufacture all kinds of connectors and special cables, have accumulated rich experience in development and prction for kinds of cables and its related connector adapter.With RED/Teradek Bond/ARRI Camera Cable, Canon / Sony Camera Power Cable, SDI Cable, USB Cable, Video Cable, CCD Cable...
We supply different OEM/ODM services serve as different application and requirement.
Our prcts are widely used in kinds of harsh environment and applications, like industrial control devices, medical equipment, measuring and inspecting equipment, audio & visual equipment and military, etc.
Furthermore, it has excellent compatibility with many leading supplier.
We always adhere to the spirit of innovation, continue to intrce new prcts series include M5,M8,M9,M12,M16,M23 and other data connectors.With IP68, ISO9001,Rohs,CE, REACH certificate approved.
High Quality: CNC machine, professional engineer, skilful worker, responsible QC ensure our high quality prcts;
OEM & ODM: OEM & ODM services are welcome;
Sample policy: Free sample & sample order are accepted;
Fast delivery: 3~5 working days after receiving payment for normal connectors;
Fast Respond: within 24 hours for your inquiry and any other questions;
After-sale Service: Follow up your shipment. Provide professional solutions for your questions.
