| Place of Origin: | CHINA |
|---|---|
| Brand Name: | RAYMO |
| Certification: | RoHs2.0 CE ISO9001 |
| Model Number: | PKG.M0.2GL.LG |
| Minimum Order Quantity: | 1 Piece/Pieces |
| Price: | Negotiable |
| Packaging Details: | Plastic Bag & Carton |
| Delivery Time: | 5-7working days |
| Payment Terms: | T/T, D/A, D/P,L/C, MoneyGram, Western Union |
| Supply Ability: | 5000Pieces/ Week |
| Prct Name: | Push Pull Connector PKG Socket | Shell Size: | 1P Series |
|---|---|---|---|
| Contact No.: | 2pin Female Contact | Insulator: | PPS |
| Shell Color: | PC Gray Colour | Shell Material: | Cuzn |
| Highlight: | PC Shell Plastic Push Pull Connectors,Plastic Push Pull Connectors PKG socket,PPS Insulator Panel Mount Socket |
||
| Shell size | 1P | Shell model | Straight plug FGG |
| Gender | Male, Female | Contact No. | 2,3,4,5,6,7,8,9,10,12,14, |
| MOQ | 1pc | Free Sample | available |
| Endurance(shell) | 5000 mating cycles | IP Level | IP40 |
| Shell material | PC | Colour options | red, black, green, blue, yellow, white, gray |
| Technical Characteristics | |||
| Temperature Range | - 40° C, +150° C | Resistance to vibrations | 15 g [10 Hz - 2000 Hz] |
| Shock Resistance | 100 g [ 6 ms] | Salt spray corrosion test | >96hr |
| Climatical Category | 50/175/21 | Shielding (min) | > 75 dB [ at 10 MHz] |
| > 40 dB [ at 1 GHz] | |||
| IP Rating | IP 68 | Certifications | ISO9001 CE ROHS2.0 SGS |
If you couldn't find exact items you want,PLS kindly email us exact models you need, best price & each model specification details will be provided to you soon. Solve the original brand's high cost and long lead time!
