| Place of Origin: | Guangdong, China |
|---|---|
| Brand Name: | RAYMO |
| Certification: | CE ROHS2.0 REACH ISO:9001-2015 |
| Model Number: | RM-S-AF1S-P19JS-052/DBPU-AF1S-P19KS |
| Minimum Order Quantity: | >=1 Pieces |
| Price: | Negotiable |
| Packaging Details: | Plastic bag and carton |
| Supply Ability: | 5000 Piece/Pieces per Week |
| Type: | Waterproof Plug | Application: | Audio & Video |
|---|---|---|---|
| Gender: | Male And Female | Certificate: | ISO9001/CE/ROHS/SGS |
| IP Rating: | IP68 | Shell Style /model: | Straight Plug And Fixed Socket |
| Housing Material: | Black /natural Chrmoe-plated Brass | Contact No: | 10,12,15,19pins |
| Insulator: | PPS | Contact Type: | Solder Type |
| Cable Accembled Or Not: | YES | Max. Mating: | 5000 |
| MOQ: | No MOQ Limit | Port: | SHENZHEN |
| Highlight: | waterproof wire connectors,waterproof cable connector |
||
|
Technical Characteristics
|
|||
|
Endurance(shell)
|
5000 mating cycles
|
Humidity
|
up to 95% at 60° C/140F
|
|
Temperature Range
|
- 65° C, +200° C
|
Resistance to vibrations
|
15 g [10 Hz - 2000 Hz]
|
|
Shock Resistance
|
100 g [ 6 ms]
|
Salt spray corrosion test
|
>96 hr
|
|
Climatical Category
|
50/175/21
|
Shielding (min)
|
> 75 dB [ at 10 MHz], > 40 dB [ at 1 GHz]
|
|
IP Rating
|
IP 68
|
Certifications
|
ISO9001/CE/ROSH/SGS
|
|
RM-S-AF1S-P19JS-052/RM-DBPU-AF1S-P19KS
|
|||
|
Shell model
|
S straight plug / DBPU socket
|
Shell size
|
1031 series/ AF
|
|
Gender
|
Male and female
|
Contact No.
|
10,12,15,19
|
|
MOQ
|
no limit
|
Delivery
|
3-5 working days
|
1. Security of the push-pull self-latching system;
2. Multipole types with 2 to 19 pins contacts;
3. Solder or PCB contacts(straight or elbow);
4. 360°screening for full EMC shielding;
5. High-density installation for space-saving ;
6. Multiple key options to avoid cross mating of similar connectors;
7. Made of bronze beryllium and have a gold-plated surface;
8. Have brass out shells which have a chrome nickel-plated surface.
Automotive, Audio-video, Aviation, Communications, Industrial Control, Information Systems, and Machines, Medical, Military, Test and Measurement, Data Acquisition, Data Transfer Equipment. Mle Power, Sensor, Sensor Systems Instrumentation, Analysis Application.
Raymo Connectors Co., Ltd. is located in Shenzhen China. We are a professional manufacturer of connectors and cable assembly. And we are seting design, development, manufacturing as a professional manufacturer.We focus on a series of fashion accessories, a wide range of diversity, reasonable price and on-time delivery.
1. Main prcts: connectors and cable assembly
2. High quality, competitive price, fast delivery ( 5-7 working days)
3. Main market: North America, Europe, Asia, North Africa, Oceania
4. OEM Manufacturing welcome: Prct, Package...
5. No MOQ limited
6. Free sample available.
7. We will reply you for your inquiry in 24 hours.
8. after sending, we will track the prcts for you once every two days, until you get the prcts. When you got the goods, test them, and give me a feedback.If you have any questions about the problem, contact with us, we will offer the solve way for you.
1. Are your company a professional manufacturer?
Raymo: Yes, we specialized in prcing circular push pull connectors and cable assembly since 2010.
Our factory is SGS audited manufacturer and worked on www.alibaba.com more than 5 years.
2. What is the MOQ?
Raymo: No MOQ limited, small order is accepted, all is depend on customer real needs.
3. Free sample :
Raymo: Available. Any needs, please contact us.
4. What about the delivery time?
Raymo: sample for 1-2 working days, mass prction for 5-10 working days.
5.What is your payment terms?
Raymo: 100% T/T deposit when customer place order.
6. Does your prct have any warranty?
Raymo: Yes, all of our connectors can work normally after 5000 cycles mating; our factory has instruments to tested them before shipping.
Damage due to misuse, treatment and unauthorized modifications and repairs are not covered by our warranty.
PLS kindly email us exact models you need, best price & each model specification details will be provided to you soon. Solve the original brand's high cost and long lead time!
