Name: Accurate Substitute Lemo Detachable Connector High Density Installation Space Saving
Brand: Shenzhen Raymo Electronics Technology Limited
SKU: FGG.1B.310.CLAD62Z
Price: 11.10 USD
Availability: InStock

Accurate Substitute Lemo Detachable Connector High Density Installation Space Saving

Basic Information

Place of Origin:	SHENZHEN, CHINA
Brand Name:	RAYMO
Certification:	REACH, ISO:9001-2015, SGS, RoHS2.0, CE
Model Number:	FGG.1B.310.CLAD62Z

Minimum Order Quantity:	5 Piece/Pieces
Price:	Negotiable
Packaging Details:	Plastic Bag & Carton
Delivery Time:	5-7wds
Payment Terms:	Western Union, L/C, D/A, D/P, T/T
Supply Ability:	5000Pieces/ Week

Contact Now

Type:

Substitute Lemo Circular Push Pull Connectors

Shell Size:

00B, 0B, 1B,2B,3B,4B

Insulator:

PPS/PEEK

Contact No.:

2,3,4,5,6,7,9pins

IP Ranking:

IP50

Application:

Audio Video

Color:

Black Chrome (Natural Chrome Is Available)

Endurance:

5000 Times Push Pull

Highlight:

electronics component connectors

electronic cable connectors

Substitute Lemo circular push pull connectors 0B 1B 2B 3B 4B FGG.1B.310.CLAD62Z

RAYMO P/N	Lemo P/N	P/N
RM-FGG-1BC-310-JS62Z	FGG.1B.310.CLAD62Z	S21L0C-P10

Description:

FGG 3010 10pin cable mount LEMO circular push pull connector
0B 1B 2B 3B 4B size with 2-32pins for your option
100% compatible with LEMO B series / L series
high packing density for space savings
Male solder contacts(Female is available if need)
5000 times push pull

SHENZHEN RAYMO ELECTRONICS TECHNOLOGY LIMITED is a manufacturer located in Shenzhen, focusing on manufacturing Creative customer-oriented circular push pull connector and cable assemblies to serve over 75 countries and regions since 2010. Our prcts got very popular recommendation among our customers

Shell size	Contacts no. ( Both with Solder & PCB type )
Shell size	Contacts no. ( Both with Solder & PCB type )
00	2	3	4
0B	2	3	4	5	6	7	9
1B	2	3	4	5	6	7	8	10	12	14	16
2B	2	3	4	5	6	7	8	10	12	14	16	19
3B	3	4	6	8/(6+2)	9(8+1)	10	12	14(13+1)	14	16	18	21	26	30	32
4B	7	10	24

RAYMO's high quality connectors are found in a variety of challenging applications and environments including:
Automotive, Audio-video, Aviation, Communications, Industrial Control, Information Systems, and Machines, Medical, Military, Test and Measurement, Data Acquisition, Data Transfer Equipment. Mle Power, Sensor,Sensor Systems Instrumentation, Analysis Application

Technical Characteristics
Temperature Range	- 65° C, +200° C	Resistance to vibrations	15 g [10 Hz - 2000 Hz]
Shell Material	Brass with chrome plated	Humidity	up to 95% at 60° C/140F
Shock Resistance	100 g [ 6 ms]	Salt spray corrosion test	>144hr
Climatical Category	50/175/21	Shielding (min)	> 75 dB [ at 10 MHz], > 40 dB [ at 1 GHz]
IP Rating	IP50	Endurance(shell)	5000 mating cycles

Why choose us:

100% compatible lemo connector
Help you save at least 50% cost
Cable assembly offer,help you save prction time

If you couldn't find exact items you want,PLS kindly email us exact models you need, best price & each model specification details will be provided to you soon. Solve the original brand's high cost and long lead time!
