| Place of Origin: | CHINA |
|---|---|
| Brand Name: | RAYMO |
| Certification: | ISO:9001-2015 CE ROHS SGS |
| Model Number: | RM-PAG-1PC-306JS52ZA |
| Minimum Order Quantity: | 1 Piece/Pieces |
| Price: | Negotiable |
| Packaging Details: | Plastic Bag & Carton |
| Delivery Time: | 5-7working days |
| Payment Terms: | T/T, L/C, T/T, Western Union, D/A, D/P |
| Supply Ability: | 5000Pieces/ Week |
| Prct Name: | Plastic Push Pull Connector | Type: | Compatible With Lemo Connector P Series, S M Series |
|---|---|---|---|
| Model: | PAG Straight Plug | Contact No.: | 2-14 Pins |
| Insulator: | PPS, PEEK | Gender: | Male, Female |
| Endurance: | ≥1000 Cycle | IP Ranking: | IP50 |
| Contact Type: | Solder/PCB/90° PCB Contacts | Contacts Material: | Brass With Gold-plated |
| Application: | Medical, Machines, Military, Audio& Video, Automative | Cable Assembled Or Not: | Yes |
| Highlight: | electronics component connectors,cable connector plug |
||
Part No.: |
PAG.M0.6GL.AC39A / RM-PAG-1PC-306JS39A |
Prct Description: |
1P size plastic push pull connector, PAG plug, 6pin male contact, 39 cable collet, gray outer-shell with blue round nut |
Plastic Push pull locking connector P-series connector, cable to cable connector, free socket, inline connector
| Main Futures | |
| 1 | Plastic high performance push-pull Self-locking system |
| 2 | can be 100% compatible with original connector |
| 3 | one key&2 keys with different agree for choice, such as 30°,60°,80°...... |
| 4 | Different color nut for easy Identification. |
| 5 | Available solder and PCB or right angle PCB contact. |
| 6 | ISO:9001-2015, CE ,RoHS2.0, SGS, Reach |
| Technical Characteristics | |||
| Temperature Range | - 50° C, +150° C | Resistance to vibrations | 15 g [10 Hz - 2000 Hz] |
| Shell Material | PC | Humidity | up to 95% at 60° C/140F |
| Shock Resistance | 100 g [ 6 ms] | Salt spray corrosion test | >96hr |
| Climatical Category | 50/175/21 | Shielding (min) | > 75 dB [ at 10 MHz], > 40 dB [ at 1 GHz] |
| IP Rating | IP 50 | Endurance(shell) | ≥1000 mating cycles |
| Shell size | Contacts no. ( Both with Solder & PCB type ) | ||||||||||
| 1P | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 12 | 14 |
SHENZHEN RAYMO ELECTRONICS TECHNOLOGY LIMITED is a manufacturer located in Shenzhen, focusing on manufacturing Creative customer-oriented circular push pull connector and cable assemblies to serve over 75 countries and regions since 2010. Our prcts got very popular recommendation among our customers
RAYMO's high quality connectors are found in a variety of challenging applications and environments including:
Automotive, Audio-video, Aviation, Communications, Industrial Control, Information Systems, and Machines, Medical, Military, Test and Measurement, Data Acquisition, Data Transfer Equipment. Mle Power, Sensor,Sensor Systems Instrumentation, Analysis Application.
| 2020.11 | Electronica Munich, Germany |
| 2019 9.24-9.26 | Testing Expo, Shanghai |
| 2018 11.12-11.15 | Electronica Munich, Germany |
| 2017 9.11-9.16 | NAB Show,Netherlands |
| 2016 4.11-4.15 | HK Fair |
| 2015 10.2-10.7 | ICEEB, Brasil |
| 2014 10.11-10.15 | HK Fair |
| 2014 4.11-4.15 | HK Fair |
1. What about the delivery time?
Raymo: sample for 3-5 working days, mass prction for 5-7 working days.
2. Are your company a professional manufacturer?
Raymo: Yes, we specialized in prcing Circular Connectors and cable assembly since 2010.
Our factory is SGS audited manufacturer and worked on www.alibaba.com more than 9 years.
3. What is the MOQ?
Raymo: No MOQ limited, small order is accepted, all is depend on customer real needs.
4. What is your payment terms?
Raymo: 100% T/T deposit when customer place order.
5. Free sample?
Raymo: Available. Any needs, please contact us.
6. Does your prct have any warranty?
Raymo: Yes, all of our connectors can work normally after 5000 cycles mating; our factory has instruments to tested them before shipping. Damage due to misuse, treatment and unauthorized modifications and repairs are not covered by our warranty.
