| Place of Origin: | SHENZHEN,CHINA |
|---|---|
| Brand Name: | RAYMO |
| Certification: | ISO9000:2015/ REACH/ CE/ ROHS/ SGS |
| Model Number: | DBEU 102 A051 130 |
| Minimum Order Quantity: | 5Piece/Pieces |
| Price: | Negotiable |
| Packaging Details: | PE Bag & Carton |
| Delivery Time: | 5-7 working days |
| Payment Terms: | Western Union, L/C, D/A, D/P, T/T |
| Supply Ability: | 10000Pieces/ Month |
| Shell Model: | Fischer Waterproof Circular Connector | Shell Size: | 102, 103, 1031, 104 |
|---|---|---|---|
| Contact No.: | 2-19pins | Contact Material: | Brass In AU Plated |
| Insulator: | PPS, PEEK | Gender: | Female, Male |
| Highlight: | waterproof electrical connectors,waterproof cable connector |
||
SHENZHEN RAYMO ELECTRONICS TECHNOLOGY LIMITED is a manufacturer located in Shenzhen, focusing on manufacturing Creative customer-oriented metal and plastic circular push-pull self-latching connectors and cable assemblies to serve over 75 countries and regions since 2010. Our prcts got very popular recommendation among our customers.
IP68 waterproof aviation connecto, Fischer socket DBPU DBPE 2pins DBEU 103 A051 139+
| Parts No: | RM-DBEU-0F1C-P02KP= DBEU 102 A051 139+ |
| Description | |
| 1 | Alternative with Fischer and F series DBPE panel socket |
| 2 | socket with PCB straight contacts |
| 3 | 102 shell size with 2pins |
| 4 | Sealed to IP68 and Hermetic |
| 5 | 360° EMC shield |
| 6 | Robust and shock resistant designs |
Different shell size and Contacts for choose:
| RM-F series | Contactv No.: | |||||||
| 0F/102 series | 2 | 3 | 4 | 5 | 6 | 7 | 9 | |
| 1F/103 series | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 10 |
| AF/1031 series | 10 | 12 | 15 | 19 | ||||
| 2F/104 series | 2 | 3 | 4 | 5 | 6 | 8 | 16 | 19 |
| Technical Characteristics | |||
| Temperature Range | - 65° C, +200° C | Resistance to vibrations | 15 g [10 Hz - 2000 Hz] |
| Shock Resistance | 100 g [ 6 ms] | Salt spray corrosion test | >144hr |
| Climatical Category | 50/175/21 | Shielding (min) | > 75 dB [ at 10 MHz] > 40 dB [ at 1 GHz] |
| IP Rating | IP 68 | Certifications | ISO9001 CE ROHS2.0 SGS |
Why choose us:
We can make all types of cables and connectors as per customers' request. Use any kind of connectors, like Hirose, Cannon, BNC, TNC, D-sub, USB, RJ45, Dtap, JST, Molex, and so on. Just tell us your need, leave the rest to RAYMO
FAQ
1. Are your company a professional manufacturer?
Raymo: Yes, we specialized in prcing Circular Connectors and cable assembly since 2010.Our factory is SGS audited manufacturer and worked on www.alibaba.com more than 9 years.
2. What is the MOQ?
Raymo: No MOQ limited, small order is accepted, all is depend on customer real needs.
3. Free sample ?
Raymo: Available. Any needs, please contact us.
4. What about the lead time?
Raymo: sample for 3-5 working days, mass prction for 5-7 working days.
5. What is your payment terms?
Raymo: 100% T/T prepayment when customer place order .
6. Does your prct have any warranty?
Raymo: Yes, all of our connectors can work normally after 5000 cycles mating; our factory has instruments to tested them before shipping. Damage due to misuse, treatment and unauthorized modifications and repairs are not covered by our warranty
