Waterproof Metal Circular Push Pull Connectors

Waterproof Metal Circular Push Pull Connectors
Waterproof Metal Circular Push Pull Connectors Waterproof Metal Circular Push Pull Connectors Waterproof Metal Circular Push Pull Connectors Waterproof Metal Circular Push Pull Connectors Waterproof Metal Circular Push Pull Connectors
Basic Information
Place of Origin: SHENZHEN,CHINA
Brand Name: RAYMO
Certification: CE/ROHS/SGS/ISO:9001-2015
Model Number: FGG.2KC.316.CLAD52Z
Minimum Order Quantity: 1 Piece/Pieces
Price: Negotiable
Packaging Details: Plastic Bag & Carton
Delivery Time: 5-7working days
Payment Terms: T/T, Western Union, D/A, D/P,L/C, MoneyGram
Supply Ability: 5000Pieces/ Week
Contact Now
Prct Name: IP68 Waterproof Push Pull Connector Model: FFG Straight Plug
Shell Size: 0K,1K,2K,3K Contact No.: 2-32 Pins
Shell Color: Natural Or Black Shell Insulator: PPS, PEEK
Gender: Male, Female Contact Type: Solder/PCB/90° PCB Contacts
IP Ranking: IP68 Cable Assembled Or Not: Yes
Highlight:

waterproof electrical connectors

,

waterproof cable connector

Prct Description

RM-K Series  0K 1K 2K 3K series FGG Straight plug

Part No.:

FFG.2K.316.CLAD52Z/ RM-FGG-2KC-316JS52Z

Prct Description:

2K size connector, FGG straight plug, 16pin male contact, 52 cable collet, nut for a bend relief, natural chrome plated shell in brass



K series Push pull locking metal connector, cable to cable connector, free socket, inline connector

Main Futures
1 Waterproof Secure high performance push-pull Self-locking system
2 100% compatible with original Lemo connector
3 2-32pin available
4 can plated with white or black chrome
5 Available solder and PCB or right angle PCB contact.
6 360° EMC shield
7 Certificate:ISO:9001-2015, CE ,RoHS2.0, SGS, Reach





Technical Characteristics
Temperature Range - 65° C, +200° C Resistance to vibrations 15 g [10 Hz - 2000 Hz]
Shell Material Brass with chrome plated Humidity up to 95% at 60° C/140F
Shock Resistance 100 g [ 6 ms] Salt spray corrosion test >144hr
Climatical Category 55/175/21 Shielding (min) > 95dB [ at 10 MHz],     > 80 dB [ at 1 GHz]
IP Rating IP 68 Endurance(shell) ≥5000 mating cycles





Waterproof Metal Circular Push Pull Connectors 0

Shell size Contacts no. ( Both with Solder & PCB type )
0K 2 3 4 5 6 7 9 　 　 　 　 　
1K 2 3 4 5 6 7 8 10 12 14 16 　
2K 2 3 4 5 6 7 8 10 12 14 16 19
3K 3 4 6 8 9 10 12 14 14 16 18 21
26 30 32 　 　 　 　 　 　 　 　 　



Our Company



RAYMO's high quality connectors are found in a variety of challenging applications and environments including:
Automotive, Audio-video, Aviation, Communications, Industrial Control, Information Systems, and Machines, Medical, Military, Test and Measurement, Data Acquisition, Data Transfer Equipment. Mle Power, Sensor,Sensor Systems Instrumentation, Analysis Application

Our Exhibition

2020.11 Electronica Munich, Germany
2019 9.24-9.26 Testing Expo, Shanghai
2018 11.12-11.15 Electronica Munich, Germany
2017 9.11-9.16 NAB Show,Netherlands
2016 4.11-4.15 HK Fair
2015 10.2-10.7 ICEEB, Brasil
2014 10.11-10.15 HK Fair
2014 4.11-4.15 HK Fair

Why Choose US?

Waterproof Metal Circular Push Pull Connectors 1

If you couldn't find exact items you want,PLS kindly email us exact models you need, best price & each model specification details will be provided to you soon. Solve the original brand's high cost and long lead time!
