| Place of Origin: | Guangdong, China |
|---|---|
| Brand Name: | RAYMO |
| Certification: | CE / RoHS / SGS / ISO9001:2015 |
| Model Number: | RM-FPG-1KC-308JS62Z |
| Minimum Order Quantity: | 1 pcs |
| Price: | Negotiable |
| Packaging Details: | PE bag & carton |
| Delivery Time: | 5-8 working days |
| Payment Terms: | T/T |
| Supply Ability: | 5000pcs per week |
| Connector Style: | FPG Elbow Plug | Series: | 1K Series (0K Series Is Available) |
|---|---|---|---|
| Contact No.: | 8 Pin （2, 3, 4, 6 ...... 16 Pin Are Available) | Keying: | 1 Key (G, 0 Degrees) (2 Keys Are Available) |
| IP Rating: | IP68 | Housing Material: | Brass |
| Housing Color: | Natural Chrome | Contact Materials: | Brass With Gold Plated |
| Rated Current: | 5 A | Contact Dia.: | 0.7 Mm |
| Insulator: | PPS Or PEEK | Manufactural: | Yes |
| Cable Assemblies: | Yes | Export Port: | Shenzhen |
| Highlight: | waterproof wire connectors,waterproof cable connector |
||
P/N: RM-FPG-1KC-308JS62Z (FPG.1K.308.CLAC60Z)
Description: FHG 1K series elbow (90 degrees) plug, 1 key, 0 degrees, 8pin male solder contacts, outer shell in natural chrome-plated brass, PPS insulator, 62 cable collet for 5.2-6.2mm cable, nut for fitting bend relief.
|
Shell size
|
Contacts No. with solder & PCB type |
|
0K
|
2 3 4 5 6 7 9
|
|
1K
|
2 3 4 5 6 7 8 10 12 14 16
|
|
2K
|
2 3 4 5 6 7 8 10 12 14 16 19 26
|
|
3K
|
3 4 6 7 8 10 12 14 16 18 21 30
|
– Watertight connection (IP 68/IP 66)
– Multipole types 2 to 30 contacts
– Solder or print (straight or elbow) contacts
– Keying system («G» key standard) for connector alignment
– Multiple key options to avoid cross mating of similar connectors
– 360° screening for full EMC shielding
– High packing density for space savings
– Rugged housing for extreme working conditions.
– Can be 100% compatible with original connectors
– High quality with reasonable prices
| Technical Characteristics | |||
| Endurance | >5000 cycles | Salt spray corrosion test | >96h |
| Humidity | Up to 95% at 60℃ | Protection Index (mated) | IP68 |
| Temperature Range | -55°C~250°C (-20°C~100°C for waterproof type) |
Climatical category | 55/175/21 |
| Resistance to Vibration | 10-2000Hz,15g | Shielding |
>95db at 10MHZ
>80db at 1GHZ
|
| Shock Resistance | >100g, 6ms | Certification | CE, RoHS, SGS ISO9001:2019 |
RAYMO's high quality connectors are found in a variety of challenging applications and environmetns including:
Automotive, Audio-video, Aviation, Communications, Industrial Control, Information Systems, and Machines, Medical, Military, Test and Measurement, Data Acquisition, Data Transfer Equipment. Mle Power, Sensor, Sensor Systems Instrumentation, Analysis Application.
PE bag & Carton
1~10pcs: 3~5 working days
11~100pcs: 3~5 working days
101~500pcs: 3~5 working days
501~1000pcs: 3~5 working days
SHENZHEN RAYMO ELECTRONICS TECHNOLOGY LIMITED is a manufacturer located in Shenzhen, focusing on manufacturing, Creative customer-oriented metal and plastic circular push-pull self-latching connectors and cable assemblies to serve over 75 countries and regions since 2010.
With professional R&D and excellent craftsmanship, our factory has the ability of offering customer with much more precision connectors and cable harness solutions to meet customer's real needs in this fields.
Aimed on offering customer qualified and suitable connectors and cable assemblies, our factory has already designed and developed over 3,000 types of connectors and 1,000 kinds of OEM cable assemblies based on customer's real needs.
