| Place of Origin: | SHENZHEN,CHINA |
|---|---|
| Brand Name: | RAYMO |
| Certification: | ISO:9001-2015, CE, RoHS2.0, SGS, REACH |
| Model Number: | FGG.0B.302.KLAC52Z |
| Minimum Order Quantity: | 1 Piece/Pieces |
| Price: | Negotiable |
| Packaging Details: | Plastic Bag & Carton |
| Delivery Time: | 5-7 working days |
| Payment Terms: | Western Union, L/C, D/A, D/P, T/T, MoneyGram |
| Supply Ability: | 5000 Pieces / Week |
| Series: | Raymo B Circular Push Pull Connector | Contacts No.: | 2. 3. 4. 5. 6. 7. 9 Poles |
|---|---|---|---|
| Shell Size: | 0B, Others Shell Is Available | Insulator: | PPS, PEEK Is Available Too |
| Application: | Railways | Cycles: | 5000 Time Push Pull |
| Highlight: | electronic cable connectors,cable connector plug |
||
automotive connector FGG EGG ECG 0B 2 pin metal cable connector,Circular push pull Connector
|
·Security of the push-pull self-latching system; ·Multicore types with 2 to 32 pins; |
·Mechanical properties and environmental factors: ·Endurance>5000 cycles ·Humidity.up to 95% at 60ºC ·Temperature range:-45ºC~+125ºC ·Resistance to vibration:10-20000Hz,15g ·Shock resistance:100g.6ms ·Salt spray corrosion test >48hrs ·Protection index:IP50 |
|
Shell size |
Contacts no. ( Both with Solder & PCB type ) |
||||||||||||||
| RM-0B | 2 | 3 | 4 | 5 | 6 | 7 | 9 | ||||||||
| RM-1B | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 10 | 12 | 14 | 16 | ||||
| RM-2B | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 10 | 12 | 14 | 16 | 19 | |||
| RM-3B | 3 | 4 | 6 | 8/(6+2) | 9(8+1) | 10 | 12 | 14(13+1) | 14 | 16 | 18 | 21 | 26 | 30 | 32 |
| RM-4B | 7 | 10 | 24 | ||||||||||||
SHENZHEN RAYMO ELECTRONICS TECHNOLOGY LIMITED is a manufacturer located in Shenzhen, focusing on manufacturing Creative customer-oriented metal and plastic circular push-pull self-latching connectors and cable assemblies to serve over 75 countries and regions since 2010. Our prcts got very popular recommendation among our customers.
This vast portfolio enables you to select the ideal connector configuration to suit almost any specific requirement in most markets inclyding medical devices, test and measurement instruments, machinery, audio video broadcast, telecommunications and military
1. Are your company a professional manufacturer?
Raymo: Yes, we SGS audited manufacturer
2. What is the MOQ?
Raymo: No MOQ limited, depend on customer real needs.
3. Free sample?
Raymo: Available. Any needs, please contact us.
4. What about the delivery time?
Raymo: 3-5 working days for samples, 5-7 working days for mass prction.
5.What is your payment terms?
Raymo: 100% T/T in advance when customer place an order.
6. Does your prct have any warranty?
Raymo: Yes, all of our connectors can work normally after 5000 cycles mating, our factory has instruments to tested them before shipping. Damage due to misuse, treatment and unauthorized modifications and repairs are not covered by our warranty.
If you couldn't find exact items you want,PLS kindly email us exact models you need, best price & each model specification details will be provided to you soon. Solve the original brand's high cost and long lead time!
