| Place of Origin: | Shenzhen, China |
|---|---|
| Brand Name: | RAYMO |
| Certification: | RoHS2.0, ISO:9001-2015, CE , SGS, REACH |
| Model Number: | RM-FGG.1B.316.CLAD |
| Minimum Order Quantity: | 1piece |
| Price: | Negotiable |
| Packaging Details: | 100pc/CTN |
| Delivery Time: | 5-7 working days |
| Payment Terms: | Western Union, T/T, D/P, D/A, L/C, MoneyGram |
| Supply Ability: | 5000pcs/week |
| Prct Name: | Push Pull Connector | Type: | Male Cable Plug |
|---|---|---|---|
| Shell Size: | 1B | Contact No.: | 16 Pins |
| Terminal: | Solder | IP Ranking: | IP50 |
| Max. Mating: | 5000 | Housing: | Brass |
| Highlight: | 1B Circular Push Pull Connectors,FGG Circular Push Pull Connectors,360° EMC Circular Power Connector |
||
100% compatible with LEMO original FGG.1B.316.CLAD
| RAYMO P/N | LEMO P/N |
| RM-FGG-0BC-304-JS42Z | FGG.0B.304.CLAD42Z |
| Shell size | Contacts no. With Solder & PCB type | |||||||||||||
| 00 | 2 | 3 | 4 | |||||||||||
| 0B | 2 | 3 | 4 | 5 | 6 | 7 | 9 | |||||||
| 1B | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 10 | 12 | 14 | 16 | |||
| 2B | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 10 | 12 | 14 | 16 | 19 | 26 | |
| 3B | 3 | 4 | 7 | 8 | 10 | 12 | 14 | 16 | 18 | 21 | 30 | |||
|
Technical Characteristics
|
|||
|
Temperature Range
|
-55°C, +250°C
|
Resistance to vibrations
|
15 g [10 Hz - 2000 Hz]
|
|
Shock Resistance
|
100 g [ 6 ms]
|
Salt spray corrosion test
|
>96hrs
|
|
Climatical Category
|
50/175/21
|
Humidity
|
Up to 95% at 60°C
|
|
IP Rating
|
IP50
|
Certifications
|
ISO9001/ CE/ ROHS2.0/ SGS
|
Our Advantages
Raymo company specilized in many kinds of alternative connector such as LEMO, REDEL, , FISHCER, HIROSE, BINDER..., all our connectors can work with original well, since 2010, we keep improving our technic and offer customer with high quality prcts, for the return, we have got many good feekbacks and build a long-term and stable cooperationship.
