| Place of Origin: | Shenzhen, China |
|---|---|
| Brand Name: | RAYMO |
| Certification: | RoHS2.0, ISO:9001-2015, CE , SGS, REACH |
| Model Number: | FGG FEG 1B 2B 310 |
| Minimum Order Quantity: | 1piece |
| Price: | Negotiable |
| Packaging Details: | 100pc/CTN |
| Delivery Time: | 5-7 working days |
| Payment Terms: | Western Union, T/T, D/P, D/A, L/C, MoneyGram |
| Supply Ability: | 5000pcs/week |
| Prct Name: | Quick Release Connector | Type: | FGG FEG Plug |
|---|---|---|---|
| Shell Size: | 11-16.5mm | Contact No.: | 10 Pins |
| Terminal: | Solder | IP Ranking: | IP50/IP60 |
| Highlight: | 2B Circular Push Pull Connectors,FEG Circular Push Pull Connectors,FGG 10 Pin Circular Connector |
||
FGG FEG 1B 2B 310 push pull alternative straight cable male plug, 10 pin circular connector
For LEMO B series compatible connectors, our factory has make:
| Shell size we have | 00B, 0B, 1B, 2B, 3B |
| Model we have |
Plug: FGG, FEG, FFG, FNG, FHG, FAG Socket: EGG, ECG, EEG, EFG, EHG, EPG, EXG, HGG, HHG, HEG, RGG, PFG, PHG |
For example:
| Raymo P/N | LEMO P/N |
| RM-FGG-0BC-302-JS42Z | FGG.0B.302.CLAD42Z |
| RM-EGG-0BC-302-KP | EGG.0BC.302.CLN |
FEA.1B.310.CLAD62 = RM-FEA-1BC-310-JS62 .Straight cable plug with key(A), two keys 30 degree, 1B series, multipole 10 contacts, outer shell in natural chrome-plated brass, PPS insulator, male solder contacts, collet for 5.2-6.2mm diameter cable, nut for without bend relief, IP50.
