| Place of Origin: | CHINA |
|---|---|
| Brand Name: | Raymo |
| Certification: | CE/ROHS/REACH/SGS/ISO9001 |
| Model Number: | FGG-00B-302-CLAD35Z |
| Minimum Order Quantity: | 1pcs |
| Price: | 3.5-4.5 |
| Packaging Details: | PE BAG+ CARTON |
| Delivery Time: | 3-5 working days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 500pcs/5-7 working days |
| Type: | Circular Push Pull Connector | Shell Size: | 00B To 4B |
|---|---|---|---|
| Contacts: | 2 Pin 3pin Until 64 Pin | Colour: | Natural/Black Chrome Plated |
| Highlight: | 00b Shell Push Pull Conector,IP68 Push Pull Conector,Fgg Audio Video Cable Connector |
||
2pin Fgg 00b Series Metal Circular Male and Female Push Pull conector Audio Video Cable Connector
RAYMO metal circular male and female push pull audio vedio cable connector 2pin FGG 00B series
Model no: RM-FGG-00B-302-CLAD65
Description: raymo RM-B series straight plug, male contact , 2pin, 35cable collet one key, 0 degree
Shell size and Contact no we do have:
| Series | Shell size | Contacts no. With Solder & PCB type | ||||||||||||
| B -1P 50 | 00 | 2 | 3 | 4 | ||||||||||
| 0B | 2 | 3 | 4 | 5 | 6 | 7 | 9 | |||||||
| 1B | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 10 | 12 | 14 | 16 | |||
| 2B | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 10 | 12 | 14 | 16 | 19 | 26 | |
| 3B | 3 | 4 | 7 | 8 | 10 | 12 | 14 | 16 | 18 | 21 | 30 | |||
ADVANAGES
RAYMO is a manufactuer that:
DIY cable assembly process:
Get the cable through sleeve collet nut in order, then soldering cable wire to the insulator one by one, please importantly note the wire order
Put the split insert carrier to the soldere insulator, to keep the slot of split insert carrier mate perfect with the heave of insulator subassembly
put the collet on the right of position of cable, make sure the heave of collet mate with the slot of split insert carrier pust the insulator subassembly split insert carrier collet into the outer shell in order, make sure the heave of split insert carrier mate with the slot of outer shell
Screw the collet nut tightly Hitch the sleeve to the corresponding step of collet nut.
