| Place of Origin: | CHINA |
|---|---|
| Brand Name: | Raymo |
| Certification: | CE/ROHS/REACH/SGS/ISO9001 |
| Model Number: | HEG.0B.302.CLL |
| Minimum Order Quantity: | 1pcs |
| Price: | 3.5-4.5 |
| Packaging Details: | PE BAG+ CARTON |
| Delivery Time: | 3-5 working days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 500pcs/5-7 working days |
| Type: | Circular Push Pull Connector | Shell Size: | 0B 1B 2B 3B 4B |
|---|---|---|---|
| Contacts: | 2 Pin | Colour: | Natural Chrome Plated |
| Gender: | Female Solder Contacts | Application: | High Speed Camera |
| Insert Material/insulator: | PPS | IP Ranking: | IP54 |
| Highlight: | HGG Circular Cable Connectors,PPS Insulator Circular Cable Connectors,2B Panel Push Pull Connectors |
||
HEG HGG 0B 1B 2B Panle Metal Socket Circular Push Pull Connector
Description:
HEG.0B.302.CLL= RM-HEG.0BC.302.KS
Panle circular push pull connector, HEG 2 pins, female solder contacts, shell in natural color
RM-B series circular connectors provide the following main features:
1. Security of the Push-Pull self-latching system
2. Multiple key options to avoid cross mating
3. keying system («G» key standard)of similar connectors for connector alignment
4. 360° screening for full EMC shielding
5. Multi-pole types 2 to 46 contacts
6. Solder, print contacts (straight or elbow)
7. High packing density for space savings
Technical characteristics:
1. Endurance:> 5000 mating cycles
2. Humidity :Up to 95% at 60 ℃
3. Temperature range:-40 ℃, +250 ℃
4. Resistance to vibration :15 g[10 HZ-2000HZ]
5. Shock resistance:100 g ,6 MS
6. Salt spray corrosion test :> 96h
7. Protection index (mated) :IP50
RM-B series Shell size and Contacts of circular push pull connector
|
00B |
2pins 3pins 4pins |
|
0B |
2pins 3pins 4pins 5pins 6pins 7pins 9pins |
|
1B |
2pins 3pins 4pins 5pins 6pins 7pins 8pins pins 10pins 12pins 14pins 16 |
|
2B |
2pins 3pins 4pins 5pins 6pins 7pins 8pins 10pins 12pins 14pins 16pins 18pins 19pins 26 |
|
3B |
3pins 4pins 7pins 8pins 10pins 12pins 14pins 16pins 18pins 21pins 30pins |
Industry Application:
It is widely used on all kinds of medical equipments, specially for the signal transmission, Medical Equipment, Audio / Video, Test and Measurement, Communications prct line.
