| Place of Origin: | SHENZHEN,CHINA |
|---|---|
| Brand Name: | RAYMO |
| Certification: | SGS, REACH, RoHS2.0, ISO:9001-2015, CE |
| Model Number: | S 102 A052 140 |
| Minimum Order Quantity: | 5 Piece/Pieces |
| Price: | Negotiable |
| Packaging Details: | Plastic Bag & Carton |
| Delivery Time: | 5-7wds |
| Payment Terms: | Western Union, L/C, D/A, D/P, T/T |
| Supply Ability: | 5000Pieces/ Week |
| Description: | Circular Waterproof Connector | Shell Size: | 0F=102 |
|---|---|---|---|
| Contacts: | 3 Poles | Insulator: | PPS/PEEK |
| Color: | Black Chrome Plated Brass | Specification: | 0F 3 Pins Male Solder Connector |
| IP Ranking: | IP68 | Endurance: | 5000 Times Push Pull |
| Highlight: | Circular Waterproof Connector PPS PEEK,WSO Circular Waterproof Connector,SS SF Cable Plug Connector |
||
Cable Mouted Plug Connector S SS SF WSO Audio Vedio Circular Waterproof Connector
RM-F series circular connector in weapons and equipment of all kinds of electronic systems,
electric connector in components and devices, components, and components, electrical connection
between system and system and signal transmission, is necessary to constitute a complete system of
basic components. IP68 ranking, under water 1.5 meter works well.
RM-S-0F1S-P03JS50 = S 102 A052 140
Circular Cable Connectors straight plug, 3 poles contacts, shell in Black chrome plated brass, contacts
in gold plated brass, male solder contacts, 50 cable collet suitable for 4.2-5.2mm diameter cable
|
Size: Fischer 102, 103, 1031, 104
|
|
Pins: Pins: 2pin 3pin 4pin 5pin 6pin 7pin 8pin 9pin 10pin 12pin
|
|
Socket with vacuum tight structure
|
|
Custom cable assembly service welcome
|
|
Fast delivery time: 3-5working days for usual models
|
|
Application: Camera, medical, Instrumentation, Industry,Energy
|
|
100% compatible with Original
|
|
Temperature Range |
- 40° C, +125° C |
Resistance to vibrations |
15 g [10 Hz - 2000 Hz] |
|
Shell Material |
Brass with chrome plated |
Humidity |
up to 95% at 60° C/140F |
|
Shock Resistance |
100 g [ 6 ms] |
Salt spray corrosion test |
>96hr |
|
Climatical Category |
50/175/21 |
Shielding (min) |
> 75 dB [ at 10 MHz], > 40 dB [ at 1 GHz] |
|
IP Rating |
IP68 |
Endurance(shell) |
5000 mating cycles |
SHENZHEN RAYMO ELECTRONICS TECHNOLOGY LIMITED has been specializing in prcing Waterproof
Connector Metal Fast Lock for many years, we providing high quality waterproof metal connector Prcts.
Quality is our priority. Raymo always attach great importance to quality controlling from the very beginning to
the very end. Our factory has gained ISO9001. If you are searching for waterproof connector metal fast lock,
please feel free to contact us.
FAQ
1. Can I order a small list ?
yes, you can, 1 piece is ok.
2. What quote do you offer?
EXW, FOB, CIF and others ways according the your needs.
3. How transport?
Sea Freight, Air Freight and others Express Delivery ways for you.
4. What is the quality of your prcts guarantee?
We have passed ISO9001:2015 Quality Management System Certification
5. Do you have after-sales service?
Certainly,you can contact us at any time.
