| Place of Origin: | Shenzhen, China |
|---|---|
| Brand Name: | Raymo connector |
| Certification: | RoHS2.0, ISO:9001-2015, CE , SGS, REACH |
| Model Number: | FGG.00B.304.CLAD32Z |
| Minimum Order Quantity: | 1piece |
| Price: | Negotiable |
| Packaging Details: | 100pc/CTN |
| Delivery Time: | 5-8 working days |
| Payment Terms: | D/A, D/P, T/T, Western Union, MoneyGram, L/C |
| Supply Ability: | 5000pcs/week |
| Prct Name: | Push Pull Circular Connector | Advanced Structure: | Self-locking |
|---|---|---|---|
| Mutiple Pin: | 4 Pins | Contact: | Solder |
| Application: | Test & Measurement/Medical Equipments/Energy/Extreme | Current Rating: | 2A |
| Protection Index: | IP50 | Gender: | Male |
| Highlight: | SGS Circular Push Pull Connectors,FGG Circular Push Pull Connectors,SGS Cable Plug Connector |
||
FGG 4 Pins SGS Circular Push Pull Connectors Metal Medical Device
FGG.00B cable plug connector 4 pins metal medical device push pull
1. FGG.00B push pull connector Prct Description:
RAYMO RM-FGG-00B-304-JS32Z can 100% compatible with Lemo original FGG.00B.304.CLAD32Z, customer choose our connector as it's high quality, competitive price, fast delivery, and fast respond after-sales service.
RM-B Series offers a mlar, ergonomic, rugged and reliable circular multipole connector for applications needing quick and secure Push-Pull latching. Making it an ideal choice for test and measurement, instrumentation, medical devices, research and audio/video applications.
2. FGG.00B push pull connector metal circular push pull connector with below features:
Secure high performance push-pull self-locking system
High pin density contributing to equipment miniaturization
Shell size 00B
Contacts from 2-4pins
Alignment Key and Polarized Keying System to avoid cross-interface
360° EMC shielding
Robust and shock resistant designs
3. FGG.00B push pull connector techinical characteristics
| Temperature Range | -55°C, +250°C | Resistance to vibrations | 15 g [10 Hz - 2000 Hz] |
| Shock Resistance | 100 g [ 6 ms] | Salt spray corrosion test | >96hrs |
| Climatical Category | 50/175/21 | Humidity | Up to 95% at 60°C |
| IP Rating | IP50 | Certifications | ISO9001/ CE/ ROHS2.0/ SGS |
4. FGG.00B push pull connector Application
•Army, Navy, Air Force, Gendarmerie, Ministry of National Defense and Coast Guard
•Medical equipments like Disposable equipment
•Test & measurement like Data acquisition
•Broadcast, like HD and SD cameras
•Energy, like Renewable energies
•Extreme, such as Sailboat racing
