| Place of Origin: | SHENZHEN,CHINA |
|---|---|
| Brand Name: | RAYMO |
| Certification: | CE/ROHS/SGS/ISO9000 |
| Model Number: | S20F1C-P07MCC0-500S |
| Minimum Order Quantity: | 1 Piece/Pieces |
| Price: | Negotiable |
| Packaging Details: | Plastic Bag & Carton |
| Delivery Time: | 5-7 working days |
| Payment Terms: | Western Union, L/C, D/A, D/P, T/T |
| Supply Ability: | 5000Pieces/ Week |
| Shell Model: | Circular Waterproof Connector | Housing Material: | Brass |
|---|---|---|---|
| Color: | Natural Chrome Plated | Shell Size: | 0F/102, 1F/103, AF/1031, 2F/104 |
| Contact No.: | 2pin 3pin 4pin 5pin 6pin 7pin 8pin 9pin 10pin 12pin 16 Pin 19 Pin | IP Ranking: | IP68 |
| Cable Assemble: | According Customer Needs | Cycles: | 5000 Times |
| Highlight: | Push Pull Circular Waterproof Connector,Brass Housing Push Pull Circular Connector,Push Pull Circular Connector IP68 |
||
Prct Description RAYMO RM-F S2 Circular Push Pull waterproof Connector
P/N: RAYMO RM-S-0F1C-P07-JS50= connector S20F1C-P07MCC0-500S
S 0F1C circular push pull waterproof connectors can intermateable with S2 connector but cheaper. ShenZhen Raymo Electronic is a professional push pull connectors manufacturer integrating connectors research and development, Prction and sales!
Offer this range of push pull circular connectors specifically designed for applications that require secure and precise connector signal integrity.
Except connectors, we can do cable assemble too, according customer real needs.
|
Category
|
Connectors, Interconnects
|
|
Circular Connectors
|
|
|
Mfr
|
|
|
Series
|
MINI-SNAP® F
|
|
Package
|
Bulk
|
|
Prct Status
|
Active
|
|
Connector Type
|
Plug, Male Pins
|
|
Number of Positions
|
7
|
|
Mounting Type
|
Free Hanging (In-Line)
|
|
Termination
|
Solder Cup
|
|
Fastening Type
|
Push-Pull
|
|
Primary Material
|
Metal
|
|
Shell Material
|
Brass
|
|
Shell Finish
|
Chrome over Nickel
|
|
Contact Finish - Mating
|
Gold
|
|
Color
|
Silver
|
|
Ingress Protection
|
IP50 - Dust Protected
|
|
Material Flammability Rating
|
UL94 V-0
|
|
Features
|
Backshell, Strain Relief
|
|
Shielding
|
Shielded
|
|
Cable Opening
|
0.177" ~ 0.197" (4.50mm ~ 5.00mm)
|
|
Operating Temperature
|
-40°C ~ 120°C
|
|
Backshell Material, Plating
|
Brass, Chrome over Nickel
|
|
Contact Material
|
Brass
|
|
Insert Material
|
PPS/PEEK
|
|
Applications
|
Industrial, Medical, Military, Testing Equipment & Measurement
|
RAYMO Circular Waterproof Push Pull Connector Application
Push pull connectors prevent accidental disconnects with a simple but fast strong-locking mechanism that is only released by squeezing the connector body. Push pull connectors are suitable for high-reliability and high-quality applications in medical, instrumentation, military, and communications, where a fast method to connect/disconnect is required. RAYMO provides quick access to push pull connectors from LEMO/FISCHER//BINDER/HIROSE. RAYMO can also provide custom cable assemblies to suit your application requirements. Not sure what push pull connectors you need? Please contact with us.
Packing & Delivery for Raymo Circular Push Pull Connector
PE bag & Carton
Delivery Time:
1~10pcs: 3~5 working days
11~100pcs: 3~5 working days
101~500pcs: 3~5 working days
501~1000pcs: 3~5 working days
About Raymo Circular Push Pull Connector
Raymo is a manufacturer located in Shenzhen, focusing on manufacturing mental and plastic circulor push-pull connectors and cable assemblies to serve over 75 countries and regions since 2010.Prcts can be 100% compatible with original ones(LEMOS,FISCHERS,HIROSE,BINDERS SRIES)
1. High Quality: CNC machine, professional engineer, skilful worker, responsible QC ensure our high quality prcts;
2. OEM & ODM: OEM & ODM services are welcome;
3. Sample policy: Free sample & sample order are accepted;
4. Fast delivery: 3~5 working days after receiving payment for normal connectors;
5. Fast Respond: within 24 hours for your inquiry and any other questions;
6. After-sale Service: Follow up your shipment. Provide professional solutions for your questions.
