RAYMO 3K.93C SMPTE Hybrid Fiber Optic Connector Plug 2 Fiber 2 Power Contacts IP68 Broadcast

3K.93C SMPTE Hybrid Fiber Optic Connector for Broadcast Camera Links

The RAYMO 3K.93C hybrid connector combines 2 single-mode optical fiber contacts and 2 electrical power contacts in one circular shell, so a single cable delivers both UHD video signal and camera power on set. It is the standard interface for SMPTE 311M camera channels used in studios, OB vans, rental houses and mobile production units.

Key Features

• Hybrid contact layout – 2 ceramic ferrule fiber contacts (1.25 mm) plus 2 power contacts rated 10 A / 250 V in one mating face
• Push-pull self-latching – three-key polarization prevents wrong mating; lock release sleeve works with gloves in the field
• IP68 sealed when mated – double O-ring seal on plug and receptacle, suitable for rain, dust and washdown use
• 360 degree EMI shielding – chrome plated brass shell with ground contact tab, typically over 75 dB shielding effectiveness
• Field serviceable – solder or crimp contact inserts are replaceable on site without replacing the whole connector
• Long mating life – 5000 mating cycles minimum with stable insertion and withdrawal force

Technical Specifications

Applications

HDTV and 4K/8K camera channels, studio pedestal and tripod heads, OB truck patch panels, stage and outside broadcast rental fleets, medical imaging carts and ruggedized sensor links where one hybrid run is preferred over separate fiber and power cables.

Ordering and Service

Plug, panel mount receptacle and cable clamp backshell are quoted separately so you can build the exact set you need. Solder or crimp contacts, straight or 90 degree backshells and custom keying are available. OEM marking, custom cable assemblies and neutral packaging are supported from 5 pieces.
